B-6 Rear Jumper Locations and Pin Definitions
JP61
Explanation of Jumpers
To modify the operation of the backplane,
jumpers can be used to choose between
optional settings. Jumpers create shorts
between two pins to change the function
of the connector. Pin 1 is identified with
a square solder pad on the printed circuit
board. Note: On two pin jumpers, "Closed"
means the jumper is on and "Open" means
the jumper is off the pins.
Appendix B: SAS-846TQ Backplane Specifications
JP97
JP98
JP99
JP100
JP129
JP62
Figure B-3: Rear Jumpers
B-7
JP35
JP50
JP84
JP63
Connector
Pins
Jumper
Setting
JP64
3
2
1
3
2
1
