7. Fan Connectors
The 3-pin connectors, designated FAN1,
FAN2, and FAN3, provide power to the
fans. See the table on the right for pin
definitions.
8 - 13. SAS Ports
The primary and secondary sets of SAS
ports provide expander features including
cascading and failover From right to left
the ports are primary 1/2/3 and secondary
1/2/3.
Appendix C: SAS-846EL Backplane Specifications
C-5
Fan Connectors
Pin#
Definition
1
Ground
2
+12V
3
Tachometer
