SC846 Chassis Manual
SAS/SATA
Hard Drive
4
4
Drive Carrier
Figure 4-6. Installing the Hard Drive into the Drive Carrier
3. Carefully align the mounting holes in both the drive carrier and the hard drive.
4. Secure the hard drive to the carrier using six screws.
5. Replace the drive carrier into the chassis. Make sure to close the drive carrier
handle to lock the drive carrier into place.
5
Figure 4-7. Installing the Hard Drive
4-6
