Section 8 - Maintenance

Using SNMP

Path: Maintenance > Management > SNMP
SNMP is an additional management tool that is useful when multiple routers in a network are being managed
by a central Master system. When an external SNMP manager is provided with this controller's Management
Information Base (MIB) file, the manager can update the controller's hierarchal variables to view or update
configuration parameters. The controller as a managed device has an SNMP agent that allows the MIB configuration
variables to be accessed by the Master (the SNMP manager). The Access Control List on the controller identifies
managers in the network that have read-only or read-write SNMP credentials. The Traps List outlines the port
over which notifications from this controller are provided to the SNMP community (managers) and also the
SNMP version (v1, v2c, v3) for the trap.

Configure SNMP v3 User List

Go to Maintenance > Management > SNMP > SNMP tab.
1. Right-click either admin or guest and select Edit.
D-Link DWC-2000 User Manual 243
