- Page 1 Building Networks for People Wireless Controller CLI Reference Guide DWC-2000 Ver. 1.0 Business Wireless Solution...
- Page 2 CLI Reference Guide DWC-2000 Wireless Controller Version 1.0 D-Link. Copyright © 2014 www.dlink.com...
-
Page 3: Table Of Contents
Contents Contents .......................... 1 Introduction ......................6 Configuration commands under branch WLAN ........... 35 2.1 wlan ap_management manual configure <macaddr> ............35 2.2 wlan ap_management ap_database add <macaddr> ............36 2.3 wlan ap_management ap_database edit <macaddr> ............36 2.4 wlan ap_management ap_database delete <macaddr> ...........38 2.5 wlan ap_management rf_management configure ............38 2.6 wlan ap_management poll_list configure .................39 2.7 wlan ap_management poll_list delete_ip_address <ipaddr>... - Page 4 2.29 wlan wids_security client configure ................50 2.30 wlan wlan_global_setting ap_validation configure ............51 2.31 wlan wlan_global_setting radius_server configure ............51 2.32 wlan wlan_global_setting country configure ..............52 2.33 wlan wlan_global_setting wireless_switch <enable> ............52 Configuration commands under branch LICENSE ......... 52 3.1 license list ........................52 3.2 license activate <activationKey>...
- Page 5 4.26 system group delete <row_id> ..................69 4.27 system users add ......................69 4.28 system users edit <row_id> ...................70 4.29 system users delete <row_id> ..................70 4.30 system group groupaccesscontrol configure <group_id> ..........70 4.31 system group access_control_browser add ..............71 4.32 system group access_control_browser delete <row_id> ..........71 4.33 system group access_control_ip add ................71 4.34 system group access_control_ip delete <row_id>...
- Page 6 7.1 net bandwidth profile enable <enable> ................87 7.2 net bandwidth profile add ....................87 7.3 net bandwidth profile edit <row_id> .................88 7.4 net bandwidth profile delete <row_id> ................88 7.5 net bandwidth traffic_selector add ...................89 7.6 net bandwidth traffic_selector edit <row_id> ..............89 7.7 net bandwidth traffic_selector delete <row_id>...
- Page 7 7.35 net vlan config delete <VlanId> ..................111...
-
Page 8: Introduction
Introduction The command “show Radius-Settings ?” at the CLI prompt, gives a description of all the show commands in the branch Radius-Settings , these are as follows: Display radius configuration. A RADIUS server maintains a database of user accounts used in larger environments. - Page 9 Display AP and peer show wlan ap_management discovery controllerdiscovery parameters. Display the configured show wlan ap_management channel_plan status <radio> channel plan parameters. Display the show wlan ap_management channel_plan history <radio> channel plan history. Display the show wlan ap_management channel_plan proposed channel proposed <radio>...
- Page 10 configuration parameters. Display AP code download 21 show wlan ap_conf download configuration and status. Display network 22 show wlan network status configuration parameters. Display network configuration 23 show wlan network networkid <id> parameters for specific network. Display AP association and 24 show wlan ap_conf failure_status authentication failure status.
- Page 11 Display AP configuration and 35 show wlan ap_conf database macaddr <macaddr> status for specific Display AP profile 36 show wlan ap_conf profile status parameters. Display AP profile 37 show wlan ap_conf profile radio radio parameters. Display AP profile 38 show wlan ap_conf profile radio status <id> <radio> radio parameters.
- Page 12 provisioning_status <macaddr> Provisioning status parameters. Display WS 50 show wlan ap_conf macaddr radio_status <macaddr> managed AP radio status parameters. Display the WIDS show wlan ap_conf macaddr AP rogue rf_scan_rogue_classification<macaddr> classification test results. Display RF Scan 52 show wlan ap_conf macaddr rf_scan_status <macaddr> AP status parameters.
- Page 13 Display associated 63 show wlan client summary client summary parameters. Display WS detected clients 64 show wlan client adhoc status on an ad-hoc network. Show associated client Radio 65 show wlan client rrm status Resource Measurement status parameters. Display associated 66 show wlan client status client status parameters.
- Page 14 history<macaddr> client pre-auth history status. Display detected show wlan client macaddr detected_client roam- client roam history history <macaddr> status Display the WIDS show wlan client macaddr detected_client rogue- Client rogue classification<macaddr> classification test results. Display detected show wlan client macaddr detected_client client status status <macaddr>...
- Page 15 client TSPEC statistics. Display associated 90 show wlan client macaddr tspec_status <macaddr> client TSPEC status parameters. Display status for peer wireless 91 show wlan peer_switch controllers and configuration push. Display status for 92 show wlan peer_switch configuration configuration push. Display status for 93 show wlan peer_switch peer_controller peer wireless controllers.
- Page 16 Display status for configuration 102 show wlan peer_switch configuration receive_status received from a peer controller. Display status for a peer controller 103 show wlan peer_switch configuration request_status configuration push request. Display the 104 show wlan wids_security wireless WIDS security settings. Display the WIDS 105 show wlan wids_security client Client security...
- Page 17 status information. Display controller 116 show wlan switch ipaddr status information for an IP address. Display the controller 117 show wlan switch certificate_request_status certificate request information. Display controller to associated 118 show wlan switch client_status client status parameters. Display Local 119 show wlan switch local wireless controller status parameters.
- Page 18 controller TSPEC status parameters. Display the controller 130 show wlan switch provision_status provisioning information. Display radio resource 131 show wlan rrm measurement (RRM) controller data. Display channel 132 show wlan rrm channel_load load information. Display neighbor 133 show wlan rrm neighbors information.
- Page 19 Location Table parameters for an Display all Triangulation 144 show wlan device_location ap triangulation Location Table parameters. Display Triangulation Location status 145 show wlan device_location ap triangulation status_all parameters for all device entries in the triangulation table database. Display Triangulation Location status parameters for 146 show wlan device_location ap triangulation status_located...
- Page 20 Triangulation Location status parameters for all device entries in the triangulation table database. Display Triangulation Location status show wlan device_location client triangulation parameters for status_located located device entries in the triangulation table database. Display all Triangulation Location Table 156 show wlan device_location client macaadr <macaadr> parameters for specific MAC Address.
- Page 21 The command “show POP3-Settings ?” at the CLI prompt, gives a description of all the show commands in the branch POP3-Settings , these are as follows: 1 show POP3-Settings Display POP3 configuration. The command “show POP3-Trusted-CA ?” at the CLI prompt, gives a description of all the show commands in the branch POP3-Trusted-CA , these are as follows: 1 show POP3-Trusted-CA Display POP3 Trusted Certificates.
- Page 22 Display Timezone and 16 show system time setup NTP configuration. Display traffic meter 17 show system traffic_meter configuration. Display traffic meter 18 show system traffic_meter setup configuration. Display USB 19 show system usb Configuration. System group display 20 show system users mode.
- Page 23 show security show advanced firewall advanced_network attack checks. show security Display igmp configuration. advanced_network igmp The command “show ldap-serverCheck ?” at the CLI prompt, gives a description of all the show commands in the branch ldap-serverCheck , these are as follows: 1 show ldap-serverCheck Display status of Ldap servers.
- Page 24 setup configuration. 23 show net radvd Display RADVD 24 show net radvd setup configuration. Show dynamic routing 25 show net routing dynamic setup. Show dynamic routing 26 show net routing dynamic setup Setup. 27 show net routing Displays routing setup. 28 show net routing static 29 show net routing static ipv4 show net routing static ipv4...
- Page 25 plan related parameters. Configure IP address to poll,VLAN ID for L2 5 wlan ap_management poll_list discovery or specific discovery method. wlan ap_management poll_list Configure specific discovery discovery method. Configure Local 7 wlan ap_management oui_database OUI Database. wlan wlan ap_management manual ap_management configure <macaddr>...
- Page 26 list configuration mode. wlan ap- wlan ap_management oui_database management oui- database configuration mode. wlan ap- wlan ap_management oui_database management ap- delete <ouival> database delete an oui value. Enter the AP Profile 19 wlan ap_profile configuration mode. Enter Network 20 wlan network configuration mode.
- Page 27 35 wlan captivePortal Ssid SSID configure. Configure a SSID wlan captivePortal ssid to associate to configure <ssid> captive Portal. 37 wlan captivePortal ssid show Show the ssid. Configure known 38 wlan client client parameters. wlan client 39 wlan client add <macaddr> configuration mode.
- Page 28 radius_server parameters. country code for 53 wlan wlan_global_setting country the wireless network. wlan wlan_global_setting wlan ap_validation ap_validation configure configuration mode. wlan wlan_global_setting wlan radius_server radius_server configure configuration mode. wlan wlan_global_setting country wlan country configure configuration mode. wlan wlan_global_setting Enable/Disable the wireless_switch <enable>...
- Page 29 configuration mode. system logging facility System logging facility configure <facility> configuration mode. System remote Logging 14 system logging remote configure configuration mode. System ipv6 logs 15 system logging ipv6 configure configuration mode. Configure Radius- 16 system Radius-Settings Settings. 17 system remote_management Remote Mgmt Setup.
- Page 30 System time 34 system time configure configuration mode. Traffic meter 35 system traffic_meter Configuration setup. Traffic meter 36 system traffic_meter configure configuration mode. 37 system usb USB Configuration. 38 system usb usb1 USB1 Configuration. 39 system usb usb1 configure USB1 Configuration. 40 system usb usb2 USB2 Configuration.
- Page 31 system group access_control_ip Add an ip to Access Control ips list. system group access_control_ip Delete an ip from delete <row_id> Access Control ips list. The command “util ?” at the CLI prompt, gives a description of all the configuration commands in the branch util , these are as follows: Revert to factory 1 util restore-factory-defaults...
- Page 32 avail_interfaces available interfaces for packet capture. Stop the 10 util system_check capturePackets stop packet capture. Download the util system_check capturePackets packet download <fileName> <ipAddr> capture to the host machine. Reboot the 12 util reboot system. Reboot the 13 util schedule-reboot <enable_reboot> system.
- Page 33 scheduling and management configuration. Configures the 7 qos lan cos-map cos-map for the controller port. Configures the 8 qos lan dscp-map cos-map for the controller port. lan queue 9 qos lan queue management management configuration. lan queue scheduling 10 qos lan queue scheduling-algo algorithm configuration.
- Page 34 Disables cos-to- 22 qos lan cos-to-dscp-remarking disable dscp remarking. Display status of 23 qos lan cos-to-dscp-remarking status cos-to-dscp- remarking. Configures cos- qos lan cos-to-dscp-remarking to-dscp configure <cosValue> <dscpValue> remarking. Queue management 25 qos lan queue management show configuration show. Set the queue qos lan queue scheduling-algo scheduling set <sched-algo>...
- Page 35 edit <row_id> traffic selector for a bandwidth profile. It allows you to delete a net bandwidth traffic_selector traffic selector for a delete <row_id> bandwidth profile. 11 net lan dhcp DHCP setup. DHCP Reserved IPs 12 net lan dhcp reserved_ip setup. net lan dhcp reserved_ip DHCP Reserved IPs configure <mac_address>...
- Page 36 RADVD configuration 33 net radvd pool setup. RADVD configuration 34 net radvd configure mode. RADVD Pool 35 net radvd pool add configuration mode. RADVD Pool 36 net radvd pool edit <row_id> configuration mode. RADVD pool 37 net radvd pool delete <row_id> configuration mode.
-
Page 37: Configuration Commands Under Branch Wlan
vlan port name range 1- 56 net port-vlan edit <portname> 57 net vlan-membership vlan-membership. Net vlan membership 58 net vlan-membership edit <port> for the port. Multivlan server 59 net multivlan configure. Multivlan Server 60 net multivlan subnet configure. net multiVlan subnet Multivlan server edit edit <vlanID>... -
Page 38: Wlan Ap_Management Ap_Database Add
Enable/Disable debugging debug on Managed AP. Enter the admin password debug passwd for the AP (the default is String admin. debug Enter the admin password passwd_confirm again. String debug Enable/Disable debugging enable_debug on Managed AP. Boolean choice reset Reset a WS managed AP. Boolean choice 2.2 wlan ap_management ap_database add <macaddr>... - Page 39 AP expected wired network Stand-alone AP expected wired mode. network mode Configure fixed radio radio1-802.11a/n channel/power settings. radio2- Configure fixed radio 802.11b/g/n channel/power settings. radio1-802.11a/n Configure a fixed channel channel for the radio. Unsigned integer radio1-802.11a/n Configure a fixed transmit power power for the radio.
-
Page 40: Wlan Ap_Management Ap_Database Delete
mode Configure the stand-alone security_mode AP expected security Stand Alone AP Security Mode mode. Configure the stand-alone wired-mode AP expected wired network Stand-alone AP expected wired mode. network mode Configure fixed radio radio1-802.11a/n channel/power settings. radio2- Configure fixed radio 802.11b/g/n channel/power settings. -
Page 41: Wlan Ap_Management Poll_List Configure
Configure the number of the channel channel_plan algorithm iterations that WS Unsigned history_depth <0-10> remembers. integer channel_plan Configure the interval for applying and Unsigned interval <6-24> computing channel adjustments. integer Configure the scheduled time for channel_plan time applying and computing channel String adjustments. -
Page 42: Wlan Ap_Management Poll_List Discovery Configure
2.9 wlan ap_management poll_list discovery configure Type and S.No Command Name Description Description Save poll-list discovery configuration save changes. Roll back poll-list discovery configuration cancel changes. Save poll-list discovery configuration exit changes and current mode. discovery Enable/Disable specific discovery method. discovery Enable/Disable the discovery of APs and enable_L2/VLAN... -
Page 43: Wlan Ap_Profile Edit
String hardware_type Configure hardware type. AP Hardware Types Configure the wired network detection vlan vlanid vlan id possible values 2.13 wlan ap_profile edit <profileid> Command Type and S.No Description Name Description <profileid> wlan ap_profile configuration mode. AP Profile ID save Save AP Profile settings. -
Page 44: Wlan Ap_Profile Qos Configure
current mode. Roll back AP profile radio settings cancel changes. Configure the physical mode for the mode radio interface. Enable/Disable the radio operational enable mode. Boolean choice state_isolation Enable/Disable Station Isolation. Boolean choice rts_threshold Configure the RTS threshold. Unsigned integer Enable load balancing parameters for enable_load_balancing the radio. -
Page 45: Wlan Network Configure
Description AP Profile ID <profileid> <radio> wlan ap_profile QoS configuration mode wireless radio interface save Save AP profile QoS configuration. exit Save and exit current mode. Roll back AP Profile QoS settings cancel changes. enable_wmm_mode Enable/Disable WMM mode. Boolean choice Select between AP EDCA parameters AP EDCA edca... - Page 46 mode for the network. Boolean choice Configure security mode for security-mode 802.11 Security network. Types wpa2 Configure WPA2. wpa2 key-caching wpa2 options for network. WPA2 key caching wpa2 key-caching holdtime wpa2 key holdtime for network. hold-time [0-Default value] wpa2 pre-authentication for wpa2 pre-auth network.
- Page 47 parameters. Configure WEP key related wep key index tx WEP key index type parameters. (1-4) Configure WEP key related wep key index value parameters. String Configure WEP key related wep key index enc parameters. String Configure WEP key related wep key type parameters.
-
Page 48: Wlan Network Delete
2.19 wlan network delete <networkId> S.No Command Name Description Type and Description <networkId> Delete a network Profile WLAN Network ID 2.20 wlan ap_profile ssid configure <profileid> <radio> Type and S.No Command Name Description Description AP Profile ID <profileid> <radio> Ssid for AP Profile. wireless radio interface save... -
Page 49: Wlan Client Add
permanent-user Authentication-type for user. auth-type Radius Authentication type permanent-user Captive portal profile for user. CP-profile Captive Portal Profile ID temporary-user Access Type is Temporary User. temporary-user Captive portal profile for user. CP-profile Captive Portal Profile ID 2.23 wlan client add <macaddr> Command S.No Description... -
Page 50: Wlan Peer_Controller Configure
wlan client <macaddr> MAC address AA:BB:CC:DD:EE:FF where configuration mode. each part is in the range 00-FF 2.26 wlan peer_controller configure Type and S.No Command Name Description Description Save peer controller configuration save changes. Roll back peer controller configuration cancel changes. Save peer controller configuration exit changes and current mode. -
Page 51: Wlan Wids_Security Ap Configure
2.28 wlan wids_security ap configure Type and S.No Command Name Description Description save Save Wids Security settings. Save Configurable wids security exit settings and exit current mode. Roll back Configurable wids security cancel settings changes. Enable Rogue reporting for admin admin_config_rogue Boolean configured Rogue AP's. -
Page 52: Wlan Wids_Security Client Configure
interval. Unsigned integer Enable or disable Rogue reporting for wds_device_unexpected detection of unexpected WDS Boolean devices. choice 2.29 wlan wids_security client configure Type and S.No Command Name Description Description save Save wids client settings. Save wids client settings and exit exit current mode. -
Page 53: Wlan Wlan_Global_Setting Ap_Validation Configure
integer Configure the De-Authentication threshold_value_deauth Unsigned Requests Threshold Value. integer Configure the Authentication threshold_value_auth Unsigned Requests Threshold Value. integer Configure the Probe Requests threshold_interval_probe Unsigned Threshold Value. integer Configure the Probe Requests threshold_value_probe Unsigned Threshold Value. integer Configure the Authentication threshold_auth_failure Unsigned Failures Threshold Value. -
Page 54: Wlan Wlan_Global_Setting Country Configure
2.32 wlan wlan_global_setting country configure Command Type and S.No Description Name Description save Save country configuration changes. cancel Roll back country configuration changes. Save country configuration changes and exit current mode. country Enter a country code. Country Code 2.33 wlan wlan_global_setting wireless_controller <enable> S.No Command Name Description Type and Description <enable>... -
Page 55: System Radius_Settings
Set primary server IP IP address AAA.BBB.CCC.DDD Authentication_Server_1 address. where each part is in the range 0- Set second alternative IP address AAA.BBB.CCC.DDD Authentication_Server_2 server IP address. where each part is in the range 0- Set third alternative IP address AAA.BBB.CCC.DDD Authentication_Server_3 server IP address. -
Page 56: System Pop3_Settings Pop3_Server_Configuration
alternative server IP IP address AAA.BBB.CCC.DDD address. where each part is in the range 0- Set third alternative IP address AAA.BBB.CCC.DDD Authentication_Server_3 server IP address. where each part is in the range 0- LDAP_Base_DN Set LDAP Base DN String Set second Second_LDAP_Base_DN alternative LDAP String... -
Page 57: System Pop3_Settings Pop3_Trusted_Ca
Authentication_Port_1 Set port for primary server. Port number Authentication_Port_2 Set port for secondary server. Port number Authentication_Port_3 Set port for optional server. Port number SSL_Enable_1 Enable SSL for primary server. Boolean choice SSL_Enable_2 Enable SSL for secondary server. Boolean choice SSL_Enable_3 Enable SSL for optional server. -
Page 58: System Logging Facility Configure
All Broadcast/Multicast Traffic broadcast_or_multicast_traffic_logs logs Enable/Disable Boolean choice Source mac filter logs source_mac_filter_logs Enable/Disable Boolean choice Bandwidth Limit logs bandwidth_limit_logs Enable/Disable Boolean choice ftp_logs FTP logs Enable/Disable Boolean choice Invalid ICMP Packets logs icmp_invalid_logs Enable/Disable Boolean choice Redirected ICMP Packets logs icmp_redirect_logs Enable/Disable Boolean choice... - Page 59 prefixed to both, e- String mail and Syslog messages. Set whether or not email_logs_enable system emails Boolean choice scheduled logs. Set options for email_server emailing of logs. String Set email address return_email SMTP server replies String are sent. Set email address send_to_email where logs and alerts String...
- Page 60 syslog_server syslog syslog_server server_name1 server1 syslog_server server_name2 server2 syslog_server server_name3 server3 syslog_server server_name4 server4 syslog_server server_name5 server5 syslog_server server_name6 server6 syslog_server server_name7 server7 syslog_server server_name8 server8 syslog_server server_name1 Boolean Choice Y/N enable Boolean choice IP address syslog_server server_name1 Set Syslog server. AAA.BBB.CCC.DDD name where each part is in the...
- Page 61 types syslog_server server_name3 Set Syslog facility. syslog server facility ID facility types syslog_server server_name4 Boolean Choice Y/N enable Boolean choice IP address syslog_server server_name4 Set Syslog server. AAA.BBB.CCC.DDD name where each part is in the range 0-255 syslog_server server_name4 Set Syslog severity. syslog server severity severity types syslog_server server_name4...
-
Page 62: System Logging Ipv6 Configure
IP address syslog_server server_name7 Set Syslog server. AAA.BBB.CCC.DDD name where each part is in the range 0-255 syslog_server server_name7 Set Syslog severity. syslog server severity severity types syslog_server server_name7 Set Syslog facility. syslog server facility ID facility types syslog_server server_name8 Boolean Choice Y/N enable Boolean choice... - Page 63 Save RADIUS save configuration changes. Save RADIUS exit configuration changes and exit current mode. Roll back configuration cancel changes. primary-radius- Set Primary RADIUS IP address AAA.BBB.CCC.DDD server server IP address. where each part is in the range 0- secondary-radius- Set Secondary RADIUS IP address AAA.BBB.CCC.DDD server server IP address.
-
Page 64: System Remote_Management Https Configure
configured servers. 4.11 system remote_management https configure S.No Command Name Description Type and Description Save access Management save changes for https. Save access Management exit changes for https and exit current mode. Roll back Remote Mgmt cancel changes. Enable/disable remote mgmt enable over https. -
Page 65: System Snmp Trap Configure
allow the IP to grant access to a IP address AAA.BBB.CCC.DDD particular machine. where each part is in the range 0- Set the Ending IP in case of IP address AAA.BBB.CCC.DDD to_address range. where each part is in the range 0- 4.13 system snmp trap configure <agent_ip>... -
Page 66: System Snmp Sys Configure
Save SNMP trap configuration save changes. Save SNMP v3 Users exit configuration changes and exit current mode. Roll back SNMP v3 Users cancel configuration changes. Authentication and privacy security_level Security level type for settings. SNMPv3 user list. Choose between MD5 or SHA SNMPv3 user list authentication_algo authentication. -
Page 67: System Snmp Access Edit
IP address agent The IP address of the SNMP agent. AAA.BBB.CCC.DDD where each part is in the range 0-255 The network mask used to determine the list of allowed SNMP managers. To allow IP address any IP on the network to manage the subnet_mask AAA.BBB.CCC.DDD device, enter 255.255.255.0. -
Page 68: System Snmp Access Delete
4.19 system snmp access delete <rowid> S.No Command Name Description Type and Description <rowid> SNMP access configuration mode. Unsigned integer. 4.20 system time configure Type and S.No Command Name Description Description save Save time configuration changes. Save time configuration changes and exit current mode. -
Page 69: System Traffic_Meter Configure
4.21 system traffic_meter configure Type and S.No Command Name Description Description Save traffic meter configuration save changes. Save traffic meter configuration exit changes and exit current mode. Roll back traffic meter configuration cancel changes. enable Enable/Disable the traffic meter. Boolean choice. Set traffic Limit Type 0(No limit), limit_type 1(Download only), 2(Both Directions) -
Page 70: System Usb Usb2 Configure
changes. enable Enable USB1 Boolean choice. printer_enable Enable printer USB Boolean choice. Storage_enable Enable Storage USB Boolean choice. Select the USB type usb_type 3G_USB_ADAPTOR/USB_Disc USB device type. 4.23 system usb usb2 configure Command Type and S.No Description Name Description save Save USB1 settings. -
Page 71: System Group Edit
Privilege_Type L2TP Give L2TP privilege to a group. Boolean choice. Privilege_Type Pptp Give Pptp privilege to a group. Boolean choice. Privilege_Type Xauth Give Xauth privilege to a group. Boolean choice. Privilege_Type Guest Give Guest privilege to a group. Boolean choice. Privilege_Type Give RuntimeAuth privilege to a RuntimeAuth... -
Page 72: System Users Edit
FirstName Enter the user's first name here. String. LastName Enter the user's last name here. String. password Enter the password here. String. password_confirm Re-Enter the password here. String. groupname Enter the group name here. String. 4.28 system users edit <row_id> Type and S.No Command Name Description Description... -
Page 73: System Group Access_Control_Browser Add
access control configuration and exit current mode. Roll back changes to group cancel access control configuration. deny_login Deny login. Boolean choice. deny_login_Option Deny login option. Boolean choice. allow_login_from_defined_ips Login from IP. Boolean choice. allow_login_from_defined_browsers Login from browser. Boolean choice. 4.31 system group access_control_browser add Command Type and S.No... -
Page 74: System Group Access_Control_Ip Delete
Save changes to group access exit control IP configuration and exit current mode. Roll back changes to group cancel access control IP configuration. group_id Group ID. Unsigned integer. address_type Address type. Source address type for users IP policy. IP address AAA.BBB.CCC.DDD source_address Set the source address. -
Page 75: Util System_Check Capturepackets Download
Enter “util system_check capturePackets Start the packet <interface> capture. avail_interfaces” command to get the available interfaces for packet capture. 5.5 util system_check capturePackets download <fileName> <ipAddr> S.No Command Name Description Type and Description Download the packet String <fileName> <ipAddr> capture to the host IP address AAA.BBB.CCC.DDD machine. -
Page 76: Qos Lan Status
6.1 qos lan status Type and S.No Command Name Description Description lan status Displays the status of LAN QoS. lan enable Enables QoS on LAN. lan disable Disables QoS on LAN. Configures trust mode configuration lan trustmode for the controller port. Shows the trust mode configuration in lan trustmode status the controller. -
Page 77: Qos Lan Enable
lan cos-to-dscp- Disables CoS to DSCP remarking. remarking configure 6.2 qos lan enable Type and S.No Command Name Description Description lan status Displays the status of LAN QoS. lan enable Enables QoS on LAN. lan disable Disables QoS on LAN. Configures the trust mode lan trustmode configuration in the controller. -
Page 78: Qos Lan Disable
lan queue scheduling- Shows the queue scheduling algo show algorithm on the LAN. lan cos-to-dscp- Disables CoS to DSCP remarking. remarking configure 6.3 qos lan disable Type and S.No Command Name Description Description lan status Displays the status of LAN QoS. lan enable Enables QoS on LAN. -
Page 79: Qos Lan Trustmode Cos Enable
lan queue scheduling- Sets the queue scheduling algorithm algo set in the LAN controller. lan queue scheduling- Shows the queue scheduling algo show algorithm in the LAN controller. lan cos-to-dscp- Disables CoS to DSCP remarking. remarking configure 6.4 qos lan trustmode cos enable <lanPort> Type and S.No Command Name Description... -
Page 80: Qos Lan Trustmode Dscp Enable
configuration. lan queue management Shows queue management show configuration. lan queue scheduling- Configures a queue scheduling algo algorithm. lan queue scheduling- Sets the queue scheduling algo set algorithm on the LAN. lan queue scheduling- Shows the queue scheduling algo show algorithm on the LAN. -
Page 81: Qos Lan Cos-Map Configure
lan cos-to-dscp- Disables COS to DSCP remarking. remarking disable Queues scheduling and lan queue management configuration. The LAN queue management lan queue management configuration. lan queue management Shows the queues management show configuration. lan queue scheduling- Configures queue scheduling algo algorithm. -
Page 82: Qos Lan Dscp-Map Configure
lan cos-map configure Configures CoS map for QoS. Configures a DSCP map for lan dscp-map the controller. Displays DSCP priority lan dscp-map show mapping for the controller. Configures DSCP map for lan dscp-map configure QoS. lan cos-to-dscp-remarking Enables CoS to DSCP enable remarking. - Page 83 port. Configures DSCP lan trustmode dscp based QoS for a controller port. Configures the CoS lan cos-map map for a controller port. Configures trust mode lan trustmode cos enable CoS based QoS on LAN. Configures trust mode lan trustmode dscp enable as DSCP QoS on LAN.
-
Page 84: Qos Lan Cos-To-Dscp-Remarking Enable
the LAN. lan cos-to-dscp-remarking Disables CoS to DSCP configure remarking. 6.8 qos lan cos-to-dscp-remarking enable Type and S.No Command Name Description Description lan status Displays status of LAN QoS. lan enable Enables QoS on LAN. lan disable Disables QoS on LAN. Configures trust mode configuration lan trustmode for the controller. -
Page 85: Qos Lan Cos-To-Dscp-Remarking Disable
lan queue scheduling-algo Sets the queue scheduling algorithm on the LAN. lan queue scheduling-algo Shows the queue scheduling show algorithm on the LAN. lan cos-to-dscp-remarking Disables CoS to DSCP remarking. configure 6.9 qos lan cos-to-dscp-remarking disable Type and S.No Command Name Description Description lan status... -
Page 86: Qos Lan Cos-To-Dscp-Remarking Status
Configures the queue scheduling lan queue scheduling-algo algorithm. lan queue scheduling-algo Sets the queue scheduling algorithm on the LAN. lan queue scheduling-algo Shows the queue scheduling show algorithm on the LAN. lan cos-to-dscp-remarking Disables CoS to DSCP remarking. configure 6.10 qos lan cos-to-dscp-remarking status Type and S.No Command Name Description... -
Page 87: Qos Lan Cos-To-Dscp-Remarking Configure
lan queue management Shows a queue management show configuration. Configures a queue scheduling lan queue scheduling-algo algorithm. lan queue scheduling-algo Sets a queue scheduling algorithm on the LAN. lan queue scheduling-algo Shows a queue scheduling algorithm show in the LAN. lan cos-to-dscp-remarking Disables CoS to DSCP remarking. -
Page 88: Qos Lan Queue Scheduling-Algo Set
Configures a DSCP map for lan dscp-map configure QoS. lan cos-to-dscp-remarking Enables CoS to DSCP enable remarking. lan cos-to-dscp-remarking Disables CoS to DSCP disable remarking. Queue scheduling and lan queue management configuration. LAN queue management lan queue management configuration. Shows the queue management lan queue management show configuration. -
Page 89: Configuration Commands Under Branch Net
enable DSCP QoS on LAN. lan cos-map show Shows the CoS map for LAN. lan cos-map configure Configures a CoS map for QoS. Configures a DSCP map for the lan dscp-map controller. Displays DSCP priority lan dscp-map show mapping on a controller. Configures a DSCP map for lan dscp-map configure QoS. -
Page 90: Net Bandwidth Profile Edit
configuration changes. name Unique profile name. String. type Profile type, priority or rate. Bandwidth profile type. priority Priority. Bandwidth priority type. Minimum bandwidth provided by minimum_rate Minimum bandwidth rate 0- user. Max bandwidth Kbps. Maximum bandwidth provided by maximum_rate Maximum bandwidth rate user. -
Page 91: Net Bandwidth Traffic_Selector Add
7.5 net bandwidth traffic_selector add Command S.No Description Type and Description Name Saves traffic selector save configuration changes. Saves traffic selector exit configuration changes and exits current mode. Rolls back traffic selector cancel configuration changes. profile_name Profile name. String. service_name Service name. String. -
Page 92: Net Bandwidth Traffic_Selector Delete
String. match_type IP /MAC address. Traffic selector match type. IP address AAA.BBB.CCC.DDD ip_address IP address. where each part is in the range 0- MAC address AA:BB:CC:DD:EE:FF mac_address MAC address. where each part is in the range 00- port_name Port Name. Traffic selectors port types. -
Page 93: Net Ethernet Configure
reserved IP entry. MAC address AA:BB:CC:DD:EE:FF where each part is in the range 00-FF 7.10 net ethernet configure <interface_name> Type and S.No Command Name Description Description <interface_name> Ethernet configuration mode. String. save Saves Ethernet configuration changes. Saves Ethernet configuration changes and exit exit current mode. - Page 94 Sets DHCP server’s end IP address AAA.BBB.CCC.DDD dhcp end_address address. where each part is in the range 0-255 Sets DHCP default IP address AAA.BBB.CCC.DDD dhcp default_gw gateway. where each part is in the range 0-255 IP address AAA.BBB.CCC.DDD dhcp primary_dns Sets a primary DNS server.
- Page 95 dns host_name Configures DNS host name mapping 7 mapping for the 7th row. dns host_name Configures DNS host name mapping 8 mapping for the 8th row. dns host_name mapping 1 Sets host name. String. host_name dns host_name IP address AAA.BBB.CCC.DDD Sets host name.
-
Page 96: Net Lan Default_Route Configure
0-255 dns host_name mapping 7 Sets host name. String. host_name dns host_name IP address AAA.BBB.CCC.DDD Sets host name. mapping 7 ipaddress where each part is in the range 0-255 dns host_name mapping 8 Sets host name. String. host_name dns host_name IP address AAA.BBB.CCC.DDD Sets host name. -
Page 97: Net Lan Ipv6 Pool Configure
configuration changes. Saves LAN configuration exit changes and exits current mode. Rolls back LAN cancel configuration changes. Sets system static LAN Settings. Sets system IP address static address LAN IP abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd address. where each part is in the range [0-9A-Fa-f:] static prefix_value Prefix length. -
Page 98: Net Lan Ipv6 Pool Delete
add/edit mode. abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd where each part is in the range [0-9A-Fa-f:] Saves LAN save configuration changes. Saves LAN configuration exit changes and exits current mode. Rolls back cancel configuration changes. Sets DHCPv6 IP address start_address start IP abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd address. where each part is in the range [0-9A-Fa-f:] Sets DHCPv6 IP address end_address... -
Page 99: Net Radvd Configure
Description <portName> Port management configuration mode. Port name. Saves port management configuration save changes. Saves port management configuration exit changes and exits current mode. Rolls back port management configuration cancel changes. enable Enables/Disables the port status. Boolean choice. Allows the gateway and network to auto_negotiation_enable Boolean determine the optimal port settings. -
Page 100: Net Radvd Pool Add
non-address) Auto configuration information. Choose between low/medium/high for the preference associated with this Controller’s preference radvd preference RADVD process type. This is used in RA’s to ensure all nodes on the network use the same MTU value in the cases where the LAN MTU is not well known. MTU size. -
Page 101: Net Radvd Pool Delete
Allows the prefix type to be selected as either 6to4 prefix_type ipv6 prefix or Global/Local/ISATAP. type. The SLA ID (Site-Level Aggregation Identifier) in sla_id the 6to4 address prefix is set for the interface ID on Unsigned which the advertisements are sent. integer. - Page 102 Day in which MD5 authentication first_key valid_from day Day in the format key validity starts. DD(01-31) Year in which MD5 authentication first_key valid_from year key validity starts. Year. Hour in which MD5 authentication first_key valid_from hour HH(00-23) using 24 key validity starts. hour clock first_key valid_from Minute in which MD5...
-
Page 103: Net Routing Static Ipv4 Configure
MM(01-12) second_key valid_from Day in which MD5 authentication Day in the format key validity starts. DD(01-31) second_key valid_from Year in which MD5 authentication year key validity starts. Year. second_key valid_from Hour in which MD5 authentication HH(00-23) using 24 hour key validity starts. hour clock second_key valid_from Minute in which MD5... -
Page 104: Net Routing Static Ipv6 Configure
0-255 IP address AAA.BBB.CCC.DDD subnet_mask Sets the subnet for this rule. where each part is in the range 0-255 IP address AAA.BBB.CCC.DDD gateway_address Sets the gateway IP. where each part is in the range 0-255 Sets the interface for which interface the rule applies. -
Page 105: Net Routing Static Ipv4 Delete
gateway IPV6. IP address abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd where each part is in the range [0-9A-Fa-f:] Sets the interface for interface which the rule Selects the IPV6 interface type. applies. Sets the metric metric for this route. Unsigned integer. Defines whether it’s an active_flag active IPV6 Boolean choice. - Page 106 captive portal users being created on that profile. Allows batch generation on frontdesk, checking this option allow_batch_frontdesk enables frontdesk users to Boolean generate a batch of temporary CP choice. users at one click. Idle timeout for CP users session_timeout Unsigned generated for this profile.
-
Page 107: Net Captiveportal Billing_Profile Edit
value. integer. Specifies the Start Login Value. valid_begin start_login value The account will expire after this Unsigned value. integer. Specifies the type(day/hours) of valid_begin start_login type the value. valid_begin begin_time Begin From. String. Checking this option enables the allow_modify_duration frontdesk user to modify duration Boolean limits. - Page 108 Each profile will be having a profile profile_name name to identify itself. String. This is the description of the profile_description profile. String. Checking this option will allow multiple users to use the same allow_multiple_login captive portal login credentials Boolean created for this profile to login choice.
- Page 109 Activates Start While Account valid_begin start_created Created. Activates Start While Account valid_begin start_login Login. Select between: Start While valid_begin_type Account Created, Start While Account Login, Begin From. Specifies the type (day/hours) of valid_begin start_created type value. Specifies the usage period (hours or days) of this account that is valid_begin start_created value activate when the account is...
-
Page 110: Net Captiveportal Billing_Profile Delete
Specifies the type (day/hours) of max_usage_traffic type max traffic usage value. 7.29 net captivePortal billing_profile delete <row_id> S.No Command Name Description Type and Description <row_id> Deletes a Billing Profile. Unsigned integer. 7.30 net port-vlan edit <portname> Command S.No Description Type and Description Name <portname>... - Page 111 <vlanID> Multi-VLAN server edit mode. VLAN ID possible values. Saves Multi-VLAN server save configuration changes. Rolls back Multi-VLAN server cancel configuration changes. Saves Multi-VLAN server exit configuration changes and exits current mode. IP of given Multi-VLAN subnet IP address AAA.BBB.CCC.DDD ip-address VLAN.
-
Page 112: Net Vlan Config Add
where each part is in the range 0- enable-dns- Relay gateway for the VLAN. proxy Boolean choice. 7.33 net vlan config add <vlan_id> S.No Command Name Description Type and Description <vlan_id> Add a VLAN. VLAN ID possible values. Saves VLAN configuration save changes. - Page 113 vlan-name Name for VLAN. String. Enables/disables inter-VLAN inter-vlan-routing routing. Boolean choice. showCP-profiles Available captive portal profiles. Access Type for the SSID to be captive-portal-type Captive Portal Type for configured. SSID. permanent-user Access type for permanent user. permanent-user Authentication server for user. Authentication type for auth-mode captive portal user.
