Distributed Tunnel - D-Link DWC-2000 User Manual

Section 7 - Viewing Status and Statistics
Path: Status > Wireless Information > Controller Status > Distributed Tunnel
The AP‐AP tunneling mode is used to support L3 roaming for wireless clients without forwarding any data traffic
to the wireless controller.
In the AP‐AP tunneling mode, when a client first associates with an AP in the wireless system, the AP forwards the
wireless client's data using VLAN forwarding mode. The AP the client initially associates with is called the Home
AP. The AP the client roams to is called the Association AP.
Field
Distributed Tunnel Packets
Transmitted
Distributed Tunnel Roamed Clients
Tunnel Clients
Tunnel Client Denials
D-Link DWC-2000 User Manual

Distributed Tunnel

Total number of packets sent by all APs via distributed tunnels.
Total number of client that successfully roamed away from Home AP using
distributed tunneling.
Total number of clients that are associated with an AP that are using distributed
tunneling.
Total number of clients for which the system was unable to setup a distributed
tunnel when client roamed.
Description
207
