12.2 Controlling the
Cutter

12.3 Installation

Hinges
Front Cover
(open)
Intermec EasyCoder 301 – Service Manual Ed. 3
The cutter is activated by CUT or CUT ON instructions in the
EasyCoder 301 Direct Protocol.
The following values are recommended for cutting between labels
and for variable length strip. In both cases, the start adjustment is
calculated to allow the paper web be pulled back after cutting, so
printing can start directly at the forward edge.
Labels:
Start adjust ..................................... :
Stop adjust ..................................... :
Strip:
Start adjust ..................................... :
Stop adjust ..................................... :
• Turn off the main switch and remove the power cord and
interface cable.
• Open the printer's front cover
• Turn the printer upside down and use a piercer to pry out the two
L-shaped hinge pins that hold the front cover.
• Remove the front cover completely.
Chapter 12 Paper Cutter
-250
+100
-250
+180
