d. Re-attach the door bracket using your reference marks as a guide
and tighten the bolts. Ensure that the slots in the mounting bracket
of the opener align with the slots in the door bracket, otherwise
the door bracket may have to be relocated. If the bracket cannot
be relocated, the opener may be fitted onto the axle using the
opener's saddle and bolts as follows:
i.
Using your reference marks as a guide, sit the opener on
the door mounting bracket and secure with the opener's
bolts and saddle and tighten firmly
ii.
Adjust the door position (if necessary) on the brackets so
that the door feeds smoothly into the guides. Make sure
that the centre of the door doesn't hit the lintel and that
the curtain is not pushed forward hard into the guide.
e. Remove the support and safety ropes.
NOTE - If the manual release handle is more than 1.8 metres from floor
level when the opener is installed, extend the handle to a height less
than 1.8 metres.

6.4 Installing The Wall Mounted Control Unit

a. Remove the face cover from the wall mount control unit
b. Affix the wall mount control unit
Make sure this location of the wall control unit is out of reach of children and convenient to the customer.
c. Replace the face cover.
d. Connect the network cable
p clips
.
7
e. Connect the power cord to a suitable power point, but
any moving object (e.g. the door) with the cable clips.
f. With the opener still disengaged, pull the door up and down to make sure it runs freely.

7. Programming The Opener

The three most common programs are;
Program
Dead Man Set Up
Automated Set Up
Automated Set Up with
Safety Beams
For the Dead Man Set Up and the Automated Set Up the door can not be closed by Auto-Close or by transmitters. When
Safety Beams are not installed, the controller will display the following message;
ATTENTION! No Safety Beams have been detected. "Safety Close' mode has been turned on. See
Manual for details.
Press SET to continue.
If the closing force as measured on the bottom of the door is over 400N (40kg), a Safety Beam must be installed. The
Safety Close mode can be turned off by changing the parameter in menu 6.1 (Section 16.1).
NOTE: Fitting Safety Beams enables the Auto-Close feature to become active.
(Fig.
at a height of 1.5 metres within sight of the door but away from moving parts.
3
from the wall control unit to the
2
Menu's required
Function
Menu 10.1
Setting the Limits
Safety Obstruction Force
Menu 1
Coding the Transmitter
Menu 10.1
Setting the Limits
Safety Obstruction Force
Menu 1
Coding the Transmitter
Menu 6.1
Safety Close Mode
Menu 10.1
Setting the Limits
Safety Obstruction Force
Menu 1
Coding the Transmitter
Menu 3
Auto Close Times
6.3).
.
3
GDO-10V3L2
DO NOT SWITCH
ON.
Section
11.1
12.1 and 12.2
13.1
11.1
12.1 and 12.2
13.1
16.1
11.1
12.1 and 12.2
13.1
16.3, 16.4 and 16.5
Owner Installation Instructions
Tighten Nuts
powerhead unit
and secure with
1
Secure the power cord away from
GDO-10V3L2 Toro
Fig 6.3
9
