2. Controller Input And Outputs

08
07
Fig 2.1
Light Relay Output N/O, Com,
01
N/C Contact
Lock Relay Output N/O, Com,
02
N/C Contact
Serial Interface Connector
03
12 volts 6 Amp - Hr Batteries
04
Engage/Disengagement Handle
05
Standby Battery Charger/Solar
06
Connector
4 GDO-10V3L2 Toro
09
Owner Installation Instructions
™
11
10
06
Solar Shunt
07
Standby Battery Shunt
08
Motor Connector
09
10 Amps Slow Blow Fuse
10
24 Volts Ac In Connector
11
Position Sensor Connector
12
05
12
01
02
03
04
