TOHATSU MFS 4 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FS
4
5
6B,C
/
/
odels
B No.003-21034-2
11-04 NB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFS 4 and is the answer not in the manual?

Questions and answers

Dennis Niemann
May 1, 2025

Tohatsu 15 hp 4 stroke fuel filter inside fuel tank,cleaning?

0
1 comments:
Mr. Anderson
May 16, 2025

To clean the fuel filter inside the fuel tank of a Tohatsu MFS 4 15 hp 4-stroke engine:

1. Remove dirt and water from the fuel tank if present.
2. Inspect the fuel filter for dirt, fuel residue buildup, foreign matter, or cracks.
3. If the filter is dirty or damaged, replace it.
4. When removing the fuel filter, avoid spilling fuel.
5. During installation, make sure the fuel filter is oriented in the correct direction—fuel flows in the direction of the arrow marked on the filter.

This answer is automatically generated

0
Stefan Craciun
June 3, 2025

In the Tohatsu 6 hp 4 stroke service manual I can't find the part code. Can you help me with some information; where can I find the part code?

0
