1.2 Name and Function of Each Part

1.2 NAME AND FUNCTION OF EACH PART
Appearance
IGX Series
Display Unit (Asia/Oceania Specification)
IGX Series
Display Unit (EU Specification)
IGX Series
or
or
or
or
page 4
Used to turn the power on or off.
Used to set the scale weight to zero, or increase the value on the
display.
Used to set the tare weight, or decrease the value on the display.
Used to move the digit position or finish a setting procedure.
Used to determine or call-up the setting.
IGB Series
IGB Series
IGB Series
IGX/IGB Series Operation Manual No. 0203A
