H35-10 Direct Vent Gas Fireplace
MODELS:
H35-NG10 Natural Gas
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
919-486a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
H35-LP10 Propane
Owners &
Installation Manual
H35 Product Video
www.hampton-fire.com
09.01.15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H35-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for HAMPTON BAY H35-10

  • Page 1 Owners & H35-10 Direct Vent Gas Fireplace Installation Manual H35 Product Video www.hampton-fire.com MODELS: H35-NG10 Natural Gas H35-LP10 Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2 ® The H35-10 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The model H35-10 has been approved by Warnock Hersey/ Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow.
  • Page 3: Dimensions

    UNIT DIMENSIONS WITH VERTICAL VENT COLLAR Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 4: Unit Dimensions With Horizontal Vent Collar

    UNIT DIMENSIONS WITH HORIZONTAL VENT COLLAR Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 5: Table Of Contents

    DV Stove Horizontal Termination Vent Kit ....24 Burner & Log Assembly ..........47 Dura-Vent Termination Kit ..........26 Horizontal Installations ..........27 WARRANTY Rigid Vent system ............27 Vertical Termination .............28 Warranty ..............51 Rigid Vent system ............28 Converting Class-A Metal Chimney or .......30 Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 6: Safety Decal

    The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back up in the same room where the gas appliance is installed. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 7: Requirements

    (e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 8: Installation

    DUE TO HIGH TEMPERATURES, THE Criteria for Manufactured Home Installations, APPLIANCE SHOULD BE LOCATED Sites, and Communities ANSI/NFPA 501A, and OUT OF TRAFFIC AND AWAY FROM with CAN/CSA Z240-MH Mobile Home Standard in Canada. FURNITURE AND DRAPERIES. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 9: General Safety Information

    5) Make gas connections. Refer to the "Gas circulating air passageways of the appliance Connection" section be kept clean and free from excessive lint from carpeting. Test the pilot. Must be as per diagram in the "Maintenance Instruction" section. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 10: Locating Your Gas Stove

    Extra provision for combustion air inside the room is not required. 5. Reverse steps to reinstall. 10 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 11: Optional Fan Installation

    Do not cut or remove the grounding prong from this plug. 919-520a 04.13.15 Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 12: Rotating 45 Terminations

    Phillips head screw driver. 5) Remove the safety screen. 2) Undo the top cast grill mounting bolts using 7/16" or 11mm socket. 3) Remove upper panel. 3) Remove light assembly and carefully set aside. 12 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 13: Front Cast Removal

    7) Slide the casting out of the base plate and the side bracket key hole slots and lift the front casting off the unit. 3) Remove top cast grill by pulling it up. 4) Remove light assembly and carefully set aside. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 14: Venting Introduction

    1) Wear gloves and safety glasses for protection. Vertical Termination: Position "B" 2) Exercise extreme caution when using ladders or on roof tops. 3) Be aware of electrical wiring locations in walls and ceilings. 14 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 15: Exterior Vent Terminal Locations

    * Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 16: 4" X 6-5/8" Rigid Pipe

    46DVA-ES (N/A - FPI) 4DT-OS SV4SU Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90 Wall Thimble Support/Ceiling Support 46DVA-DC SV4PF TE-4DE90B Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF Trim Plate-Black 4DT-TP 4DFPB 4DCP SV4LA 16 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 17 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fire hazard. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 18: Rigid Pipe Venting Systems

    American Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace ® Products International Ltd. Dura-Vent® and Direct Vent Pro are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. 18 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 19: Venting Arrangements

    Off, as required for manufactured homes. (Actual efficiency may be as high as 85%) May be installed in Manufactured (Mobile) Homes after first sale. NOTE: See "Vent Restrictor Position" section for installation instructions for the Vent Restrictor Position. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 20: Venting Arrangements

    *If this is an outside corner, the minimum dis- tance between the vent and the outside corner is 6” (15cm). See “F” on the diagram in the "Exterior Vent Terminal Locations" section. 20 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 21 7' Min. 7' Max. between 90 elbows is 5' Max. 9' Min. 8' Max. required. Lengths do not include elbow indicated Vent restrictor position A (fully open), refer to the "Vent Restrictor Position" section. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 22 5' Max. 5' Min. between 90 elbows is 6' Max. 6' Min. required. Lengths do not include elbow indicated Vent restrictor position A (fully open), refer to the "Vent Restrictor Position" section. 22 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 23: Vertical Termination With Co-Linear Flex System

    Note: Must remove 4 screws from stove collar and rotate 180 to have collar facing straight back. Secure into place with 4 screws. Straight Vertical Terminations Vent Restrictor set at 1-3/4" open (fully open), Position "A" Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 24: Dv Stove Horizontal Termination Vent Kit

    Cut a 9-1/2" x 9-1/2" (241mm x 241 mm) terminal. square hole on both the interior and exterior towards vent termination area. wall. 24 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 25 Hint: leave an extra 12" to 16" of length, this will out a square that the cap can be mounted make the final assembly easier to work with. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 26: Dura-Vent Termination Kit

    Alternate Pipe Length *Adj.Pipe Length Horizontal Termination Caps *90 Elbow *24" Pipe Length Dura-Vent Basic Horizontal Kit # 46DVA-KHA 1 90 Elbow 1 Wall Thimble Cover 1 Horiz. Sq. Term. Cap 26 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 27: Horizontal Installations

    The female locking lugs will not be visible from the outside on the Black Pipe or fittings. They may be located by examining the inside of the female ends. Diagram 2a Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 28: Vertical Termination

    You may wish to relocate the appliance or to offset, as shown in Diagram 8 to avoid cutting load bearing members. Diagram 6 28 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 29: Offset Chart

    1-1/4". Slip the flashing under the shingles (shingles should overlap half the flashing) as over 16/12 to 18/12 2.13 per Diagram 10. over 18/12 to 20/12 2.29 over 20/12 to 21/12 2.44 Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 30: Converting Class-A Metal Chimney Or

    Diagram 5 7) The connection between the appliance and the Retro Connector may be completed with sections of black direct vent pipe, together Diagram 2 with an adjustable length. 30 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 31: Cathedral Ceilings

    FOR LEAK TESTING. 3) Use appropriate roof flashing. Place the flashing under the upper shingles and on top of the lower shingles approximately half of the flashing should be under the shingles. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 32: Aeration Adjustment

    Note: Any damage due to carboning resulting from improperly setting the aeration controls is NOT covered under warranty. Note: Aeration Adjustment should only be performed by an authorized FPI Installer at the time of installation or service. 32 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 33: Conversion Kit #743-969 From Ng To Lp

    Remove the 2 screws, push Burner Assembly to the left and lift out. 19) Check operation of flame control. 10) Disconnect the NG stepper motor wires from the receiver in location show below. Pull off the pilot cap to expose the pilot orifice. Installer Notice: These instructions must be left with the appliance. 919-519a 04.14.15 Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 34: Back Up Battery Install

    5. Reverse steps 3-1 to reinstall. Panel Panel NOTE: Remove the batteries when normal operation is resumed as the heat will drain the bat- tery power rapidly. 6) Install the brick tabs (refer to Diagram 2). 34 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 35: Log Set Installation

    8) Place the Left Top Log D)02-46 on the pin on Log B)02-56 and on top of the cutout on Log A)02-43. A)02-43 A)02-43 D)02-46 Embers Embers B)02-56 E)02-45 C)02-44 Notch Cutout Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 36: Wall Thermostat

    Wire Size Max. Length 14 GA. 50 Ft. 16 GA. 32 Ft. 18 GA. 20 Ft. 20 GA. 12 Ft. 22 GA. 9 Ft. 36 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 37: Wiring Diagram Without Thermostat

    FLAME DETECT MAIN ON/OFF SWITCH GREY GREY 885 PROFLAME YELLOW/GREEN ORANGE PILOT GREEN BLACK BROWN YELLOW BURNER ORANGE BLACK BLACK WHITE YELLOW YELLOW WHITE VARIABLE LIGHT LOAD SWITCH: SW1 PROFLAME 2 IFC CONTROL BOARD Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 38: Wiring Diagram With Thermostat

    MAIN ON/OFF GREY SWITCH 885 PROFLAME YELLOW/GREEN ORANGE PILOT GREEN BLACK BROWN YELLOW BURNER ORANGE BLACK BLACK WHITE YELLOW YELLOW WHITE VARIABLE LIGHT LOAD SWITCH: SW1 PROFLAME 2 IFC CONTROL BOARD 38 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 39: First Fire

    (packed with remote control) to understand how to operate this remote system. You can download remote functions video with the QR code below.. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 40: Lighting Procedure

    Manual mode: Fan will turn on and off immediately using the remote control transmitter if the fan function is in the "on" position. Continuous Pilot/Intermittent Pilot (CPI/IPI) selection See remote control instructions for details. 40 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 41: Copy Of The Lighting Plate Instructions

    If service is to be performed–you must disconnect power and shut off gas to the unit. Appuyer sur la touche ON/OFF de la télécommande. Si le service est effectuée–vous devez débrancher l'alimentation et coupez le gaz à l'unité. DO NOT REMOVE THIS INSTRUCTION PLATE 919-535 Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 42: Maintenance

    When cleaning the logs, use a soft clean paint brush as the logs are fragile and easily dam- Top View of pilot flame aged. 42 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 43: General Vent Maintenance

    Do not tear or damage the flex pipe while handling glass. when removing the fan. Disconnect the green ground lug wire from the fan as soon as you can reach it. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 44: Accent Light Bulb Replacement

    3. Lift off cast top and place on a soft surface. 3) Undo the top cast grill mounting bolts using 7/16" or 11mm socket. 7. Replace screen and reverse steps to reinstall. 44 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 45: Removing Valve

    18) Remove inlet pipe with pipe wrench. Note orientation of 90 elbow. 19) Remove two (2) phillips head M5 screws on each side of the valve. 20) Remove valve and remove gas out 90 brass fitting. Note orientation of fitting. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 46: Parts List

    Cast Top Seaside Sand 743-211 Cast Left Charcoal Grey 743-215 Cast Left Timberline Brown 743-217 Cast Left Seaside Sand 743-221 Cast Right Charcoal Grey 743-225 Cast Right Timberline Brown 743-227 Cast Right Seaside Sand 46 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 47: Burner & Log Assembly

    Battery Holder W/9V Snap in 4 AA Bat teries 945F Simpson Duravent Strater Collar W8442051- Strater Collar Gasket - Outer W260108 - Starter Collar Gasket - Inner *Note: Not available as a replacement part. Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 48 48 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 49 Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 50 50 | Hampton® H35-10 Direct Vent Freestanding Gas Stove...
  • Page 51: Warranty

    Any alteration to the unit which causes sooting or carboning that results in damage to the interior / exterior facia is not the responsibility of FPI. * Subsidy according to job scale as predetermined by FPI. Hampton® H35-10 Direct Vent Freestanding Gas Stove Revised: 01-04-07...
  • Page 52 ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ H35-10 Product Video Hampton and AstroCap™ are trademarks of FPI Fireplace Products International Ltd. ® Printed in Canada © Copyright 2015, FPI Fireplace Products International Ltd. All rights reserved.
