H35 Direct Vent Gas Fireplace
WARNING:
If the information in these instructions are not followed ex-
actly, a fi re or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
Tested by:
918-518a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
www.hampton-fi re.com
MODELS:
H35-NG1 Natural Gas
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Installation Manual
H35-LP1 Propane
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fi re department.
Owners &
01/03/08
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY H35-LP1
Summary of Contents for HAMPTON BAY H35-LP1
- Page 1 Homeowner: Please keep these instructions for future reference. Owners & Installation Manual H35-LP1 Propane FOR YOUR SAFETY What to do if you smell gas: Do not try to light any appliance Do not touch any electrical switch: do not use any phone in your building.
-
Page 2: Unit Dimensions
HAMPTON ® Direct Vent Freestanding Gas Stove To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Hampton Gas Stove by FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. The H35 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fi... -
Page 3: Table Of Contents
SAFETY LABEL Copy of Safety Label ...4 REQUIREMENTS MA Code - CO Detector ...5 INSTALLATION Specifi cations ...6 Information for Mobile / Manufactured Homes After First Sale ...6 General Safety Information ...7 Installation Checklist ...7 Clearances to Combustibles ...7 Locating Your Gas Stove ...8 Manufactured Mobile Home Additional Requirements ..8 Combustion and Ventilation Air ...8 Optional Fan Installation ...8... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each Direct Vent Freestanding Gas Stove. We have printed a copy of the contents here for your review. For the State of Massachusetts, installation and repair must be done by a plumber or gasfi tter licensed in the Commonwealth of Massachusetts. -
Page 5: Requirements
REQUIREMENTS MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 6: Installation
Simpson Dura-Vent instructions. SPECIFICATIONS Fuels: H35-NG1 is approved for use with natural gas. H35-LP1 is approved for use with liquefied petroleum gases (propane). Electrical: 120V A.C. system. Circulation Fan: Variable speed, 125/75. Log Sets: Ceramic fi bre, 7 per set. -
Page 7: General Safety Information
fl oor. This unit can also be installed directly on carpeting or vinyl. Use the minimum clearances shown in the diagrams below: H35-NG1 & H35-LP1 Clearances A Side Wall to Unit 6-1/2" / 165 mm B Back Wall to Unit 6"... -
Page 8: Locating Your Gas Stove
INSTALLATION LOCATING YOUR GAS STOVE When selecting a location for your stove, ensure that the clearances listed above are met as well as ensuring that there is adequate accessibility for servicing and proper operation. Cross Corner Room Divider Island Flat on Wall Flat on Wall Corner Flush with Wall/Alcove For Vent Termination requirements, see the... -
Page 9: Venting Introduction
Dura-Vent Direct Vent System Model DV-GS venting systems, in combination with the Direct Vent Freestanding Gas Stoves, H35-NG1, and H35-LP1, have been tested and listed as direct vent heater systems by Warnock Hersey. These units use the "balanced fl ue" technology Co-Axial system. -
Page 10: Exterior Vent Terminal Locations
INSTALLATION EXTERIOR VENT TERMINAL LOCATIONS ® Hampton H35 Direct Vent Freestanding Gas Stove... -
Page 11: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
4” X 6-5/8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. Description 6” Pipe Length, Galvanized 6” Pipe Length, Black 7” Pipe Length, Galvanized 7” Pipe Length, Black 9”... - Page 12 INSTALLATION 4” x 6-5/8” Rigid Pipe Cross Reference Chart (Cont.) Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. Description Attic Insulation Shield 12” Attic Insulation Shield - 36” Cold Climates Basic Horizontal Termination Kit (A) Horizontal Termination Kit (B) Vertical Termination Kit...
-
Page 13: Horizontal Termination
Alternate Horizontal Termination Caps WARNING: Do not combine venting components from different venting systems. However use of the the AstroCap and FPI Riser is acceptable with all systems. This product has been evaluated by Intertek for use with Duravent Direct-Vent GS, Selkirk Direct-Temp, Ameri Vent Direct venting and Security Secure Vent systems. -
Page 14: Elbow For Straight Horizontal Terminations
INSTALLATION ROTATING 45 ELBOW FOR STRAIGHT HORIZONTAL TERMINATIONS 1) Remove all 4 screws that secure the elbow to the unit using a 1/4" magnetic nut driver. Remove all 4 screws and washers Horizontal Terminations for All Venting Systems The shaded areas in the diagram below show all allowable combinations of vertical runs with horizontal terminations. - Page 15 HORIZONTAL TERMINATIONS USING RIGID PIPE The two diagrams show all allowable com- binations of straight horizontal termination using Rigid Pipe. Restrictor position "A". Venting Arrangements -Straight Horizontal Termination at a De-Rated BTU The diagrams show all allowable combina- tions of straight horizontal termination using Rigid Pipe.
-
Page 16: Horizontal Venting With Two (2)
INSTALLATION One 90 elbow = Two 45 elbows. Option H + H1 With these options, maxi- 3' Min. 2' Max. mum total pipe length is 30 feet with minimum of 8 feet 4' Min. 3' Max. total vertical and maximum 5' Min. - Page 17 One 90 elbow = Two 45 Option V V + V1 1' Min. 3' Max. 2' Min. 2' Min. 4' Max. 3' Min. 3' Min. 5' Max. 4' Min. 4' Min. 6' Max. 5' Min. 5' Min. 7' Max. 6' Min. Lengths do not include elbow indicated Vent restrictor position A (fully open), refer to the "Vent Re- strcitor Postion"...
-
Page 18: Vertical Termination With Co-Linear Flex System
INSTALLATION VERTICAL TERMINATION WITH CO-LINEAR FLEX SYSTEM THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. This appliance is designed to be attached to two 3" (76mm) co-linear aluminium fl ex running the full length of the chimney. -
Page 19: Dv Stove Horizontal Vent Kit
DV STOVE HORIZONTAL VENT KIT DV 2 ft. Stove Vent Kit (Part # 946-116) and DV 4 ft. Stove Vent Kit (Part #946-216) includes all the parts needed to install the H35 Direct Vent unit with minimum horizontal and vertical vent dimensions. For installations that require longer vertical and/or horizontal vents use the Dura-Vent system as shown in the "Dura-Vent Termination Kit"... - Page 20 INSTALLATION 3) Attach the 4" dia. fl ex liner to the vent terminal ensuring that the fl ex overlaps the collar of the vent terminal by a minimum of 1-3/8"(35mm). Use Mill-Pac to seal and secure with 3 of the #8 x 1/2" screws (stain- less steel).
-
Page 21: Dura-Vent Termination Kit
Planning Your Dura-Vent Installation There are two basic types of Dura-Vent Direct Vent System installations: horizontal termination and vertical termination. Confi rm the maximum horizontal run and maximum vertical rise from the diagrams in the "Venting Arrangment" section. When planning your installation, it will be nec- essary to select the proper length of vent pipe for your particular requirements. -
Page 22: Dura-Vent Horizontal Installations
INSTALLATION DURA-VENT HORIZONTAL INSTALLATIONS 1) Set the unit in its desired location. Check to determine if wall studs or roof rafters are in the way when the venting system is attached. If this is the case, you may want to adjust the location of the unit. 2) Direct Vent pipe and fi... -
Page 23: Dura-Vent Vertical Termination
Note: a) The horizontal run of vent should have a 1/4 inch rise for every 1 foot of run towards the termination. Never allow the vent to run downward. This could cause high temperatures and may present the possibility of a fi re. b) The location of the horizontal vent termi- nation on an exterior wall must meet all local and national building codes, and... -
Page 24: Offset Chart
INSTALLATION Diagram 8 3) To install the Round Support Box/Wall Thim- ble in a fl at ceiling, cut a 10 inch square hole in the ceiling centred on the hole drilled in Step 2. Frame the hole as shown in Diagram Diagram 9 4) Assemble the desired lengths of black pipe and elbows necessary to reach from the... -
Page 25: Converting Class-A Metal Chimney Or
CONVERTING CLASS-A METAL CHIMNEY OR MASONRY CHIMNEY TO DIRECT VENT SYSTEM There are two different types of direct vent conversion systems listed below. Follow the appropriate directions for your installation. A) Through an existing factory built metal chimney going through the ceiling: A typical conversion of this type is shown in diagram 1. -
Page 26: Cathedral Ceilings
INSTALLATION CATHEDRAL CEILINGS Round Support (RDS) & Square Support (SQS) If your home has a cathedral ceiling (no attic space between the ceiling and the roof), install the chimney and support as follows. 1) Situate the chimney in a convenient loca- tion as near as possible to the appliance outlet. -
Page 27: Aeration Adjustment
AERATION ADJUSTMENT The burner aeration is factory set but may need adjusting due to either the local gas supply, air supply or altitude. Natural Gas 1/4" (6.4 mm) Propane 3/8" (9.5 mm) The aeration adjustment gears are located on the right side of the burner box. Remove the Hampton ®... -
Page 28: Conversion Kit #791-969 From Ng To Lp
INSTALLATION CONVERSION KIT #791-969 FROM NG TO LP THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Each Kit contains one LPG Conversion Kit and one DC Sparker Kit. LPG Conversion Kit Contains: Qty. -
Page 29: Installation Of The Dc Sparker
14) Using the Allen wrench as shown in Fig.4, rotate the screw clockwise until snug, do not overtighten. Fig.4 WARNING! Do not overtighten the screw. Recommended to grip the wrench by the short side. ) Verify that if the conversion is from NG to LPG, the screw must be reassembled with the red o-ring visible (Fig. - Page 30 INSTALLATION Attach the Piezo ignition wire to the DC Sparker. Piezo Ignitor Insert both the ground wire and the DC sparker generator wire through the hole of the DC spark heat shield. Install the plastic bushing over the outside of the hole. 10) Attach the ground wire to the DC spark mounting bracket.
- Page 31 Locate the ground lug at the receptical box, left of the unit. Connect one end of the supplied green ground wire to the lug with the nut and washer from the kit. Ground wire from Install the 1/2" bushing to the heat shield.
-
Page 32: Conversion Kit To Lower Btu Rating
INSTALLATION CONVERSION KIT TO LOWER BTU RATING NATURAL GAS - KIT #: 740-950 PROPANE - KIT # 740-952 THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Natural Gas Conversion Kit 740-950 Contains: Qty. -
Page 33: Optional Brick Panel
10) Adjust Vent restrictor setting: To set the Vent restriction as indicated in the diagram, simply loosen the screws and push the vent restrictor plate to the correct position. Tighten the screws. Unit Btu/h Restrictor Opening H35 NG 30,000 1-3/4" (45mm) H35 LP 28,500 1-3/4"... - Page 34 INSTALLATION 4) Place Rear Log A)02-43 on the two pins on the rear log support. A)02-43 Pins on Rear Log Support 5) Place the Middle Left Log B)02-56 on the two pins as shown. B)02-56 6) Sprinkle some lava rock just in front of B) 02-56 on the burner holes.
-
Page 35: Double Doorinstallation
DOUBLE DOOR INSTALLATION 1) Secure the Top Door Clip into the Top Front Casting. Top Door Clip 2) Pull all four door hinges out from the sides of the Front Casting. 3) Fasten the Right Door to the 2 right hinges (2 screws per hinge). -
Page 36: Door Hinge Removal
INSTALLATION DOOR HINGE REMOVAL 1) Remove the cast top by lifting it off of the stove. 2) Release the catches on the left and right side of the stove that secure the glass. Release catch by pulling up. 3) Remove the glass by sliding it up and out. 4) Pull all four door hinges out from the sides of the front casting. -
Page 37: Wiring Diagrams
If any of the original wires as supplied with the appliance must be replaced, it must be replaced with CSA type SEW (200 C) or its equivalent. This heater does not require a 120V A.C. sup- ply for operation. In case of a power failure, the burner switch and the optional remote control/ thermostat will continue to operate. -
Page 38: Wall Thermostat
INSTALLATION PROPANE *For installation of the DC Spark Box refer to the LP Conversion instructions in this manual. WALL THERMOSTAT A wall thermostat may be installed if desired. Connect the wires as per the wiring diagrams. Note that the wires are connected to the "TH" on the gas valve. -
Page 39: Final Check
1) Choose a convenient location on the wall to install the receiver and the receptacle box (protection from extreme heat is very important). Run wires from the fi replace to that location, use Thermostat Wire Table. 2) Connect the wires as per the wiring diagram below. -
Page 40: Copy Of The Lighting Plate Instructions
OPERATING INSTRUCTIONS COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/ NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. (Australia: AS5601-2004, New Zealand: NZS 5261) WARNING: If you do not follow these instructions exactly, a fi... -
Page 41: Maintenance
NORMAL OPERATING SOUNDS OF GAS APPLIANCES It is possible that you will hear some sounds from your gas appliance. This is perfectly normal due to the fact that there are various gauges and types of steel used within your appliance. Listed below are some examples. -
Page 42: Fan Maintenance
MAINTENANCE GENERAL VENT MAINTENANCE Conduct an inspection of the venting system semi-annually. Recommended areas to inspect as follows: 1) Check the Venting System for corrosion in areas that are exposed to the elements. These will appear as rust spots or streaks, and in extreme cases, holes. -
Page 43: Removing Valve
Replacing the Fan: Reverse the above steps (1 - 4). Make sure the fan wires and the ground wire are reattached. Hint for pushing fan down onto pins - rub a bit of dish soap on the grommet so it will slide more easily onto the pin. -
Page 44: Parts List
PARTS LIST Part # Description 942-301** Casting - Top 942-311** Casting - Top Grill 942-321** Casting - Left Side 942-331** Casting - Right Side 942-341** Casting - Front 740-931** Casting - Double Door 942-371** Casting - Bottom Skirt 942-381** Casting - Leg 942-391** Casting - Insert Plate - Top 942-401**... -
Page 45: Burner & Log Assembly
Description Part # 740-574/P Valve Assembly S.I.T. - Natural Gas 740-576/P Valve Assembly S.I.T. - Propane 910-478 Valve S.I.T. - NG/LP 904-689 #33 Orifi ce - N.G. 904-645 #51 Orifi ce - LP 910-190 Piezo Ignitor & Nut 908-672 Control Panel Decal 490-061 Switch Plate 910-897... - Page 46 NOTES ® Hampton H35 Direct Vent Freestanding Gas Stove...
-
Page 47: Warranty
WARRANTY Hampton Fireplace Products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our facility. FPI Fireplace Products International Ltd. is pleased to extend this limited lifetime warranty to the original purchaser of a Hampton Product. - Page 48 Hampton reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our door. FPI Fireplace Products International Ltd. is pleased to extend this Limited Lifetime Warranty to the original purchaser of a Hampton See the inside back cover for details.
