HAMPTON BAY H27 Owners & Installation Manual
Direct vent gas fireplace
Hide thumbs
Also See for H27:
- Owners & installation manual (48 pages) ,
- Owners & installation manual (48 pages)
Table of Contents
Advertisement
Quick Links
H27 Direct Vent Gas Fireplace
MODELS:
H27E-NG11 Natural Gas
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certifiedto/Certifiépour:CSA2.17-2017
ANSIZ21.88-2017
CSA2.33-2017
920-043b
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
H27E-LP11 Propane
Installer: P leasecompletethedetailsonthebackcover
andleavethismanualwiththehomeowner.
Homeowner: Pleasekeeptheseinstructionsforfuturereference.
Owners &
Installation Manual
www.hampton-fire.com
06.18.20
