Remote Control Operation
There are two methods for remotely controlling current and voltage adjustments. Current must be
controlled for both methods otherwise the unit will default to CC mode.
REMOTE CONTROL – METHOD 1: Using two external DC voltage sources
Remote Socket Pin Assignment for external variable voltage source
PIN
1
2
3
4
5
6
7
8
Check the output voltage range of the power supply by varying the external voltage source.
Short circuit the main output with 10AWG wire to check the CC setting on the display while
varying the external voltage source.
FUNCTIONS
Internal DC +5V
Voltage adjust
Current adjust
Ground
Output OFF
N.A.
N.A.
N.A.
REMARKS
Lower than 50mA
0 to 5V Externes VDC‐Signal
0 to 5V Externes VDC‐Signal
Short to ground
9
DCP60‐EU‐DE v1.4 9/13
