HOW TO USE THE SOFTWARE
STARTING THE SOFTWARE
To run the
EVAL-AD5629RSDZ/EVAL-AD5669RSDZ
take the following steps:
1.
Connect the evaluation board to the
connect the USB cable from the
2.
Power the
SDP-B
board and the evaluation board by
connecting 5 V to Connector J2.
3.
Click Start > All Programs > Analog Devices >
AD5629R/AD5669R > AD5629R/AD5669R Evaluation
Software. While the software connects to the evaluation
board, the message in Figure 3 displays.
Figure 3. Connection Message
EVAL-AD5629RSDZ/EVAL-AD5669RSDZ User Guide
software,
SDP-B
board and
SDP-B
board to the PC.
Figure 5.
AD5629R/AD5669R
Rev. 0 | Page 8 of 14
If the
SDP-B
board is not connected to the USB port when the
software launches, a connectivity error displays (see Figure 4).
Connect the
SDP-B
board to the USB port of the PC, wait at
least 40 sec for the
SDP-B
follow the instructions.
Alternatively, the software can be used without an evaluation
board. The software runs in simulation mode displaying
expected outputs based on the input data. The main window
of the
AD5629R/AD5669R
shown in Figure 5.
Evaluation Software Main Window
Figure 4. Connectivity Error
board to boot, click Rescan, and
evaluation software then opens, as
