SOFTWARE SETUP

The AD-BMSE2E3W-SL GUI, also referred as the Light EV BMS
GUI, is a PC-based graphical user interface (GUI) tool designed to
work in conjunction with the ADBMSE2E3W-SL board.
A MyAnalog.com account is required to download the software.
Follow these steps to create a MyAnalog account:
1. Go to MyAnalog and create an account using email. Select
Register with email to get started.
2. Log in to MyAnalog using credentials.
Request for Software Access
To request for software access, send the following details to this
email address: LEV_CSESupport@analog.com
MyAnalog email address
►
Company
►
Country
►
Purpose/Projects
►

DOWNLOAD

1. Click this link: AD-BMSE2E3W-SL Version 1.0.0
2. The Software Package Download page opens. Tick the check
box and click I Accept to accept the license agreement.
3. Click Download to download the installer.
Note: When software updates or new versions of the software
are available, Analog Devices sends a notification to the email
address associated with the MyAnalog account used to download
the original software package.

GRAPHICAL USER INTERFACE (GUI) SETUP

1. Double-click on ad-bmse2e3w-sl-rel1.0.0.exe to install the pro-
gram to your computer.
2. Accept the license terms and click Next to proceed with the
installation. The default installation directory is in C:\Analog
Devices\.
3. Locate the light_ev_bmsv1.0.0.hex file inside the AD-
BMSE2E3W-SL installer files folder. C:\Analog Devices\AD-
BMSE2E3W-SL-Rel1.0.0\Software\Firmware
4. Drag and drop the .hex file into the DAPLink drive to flash the
program on the MCU.
5. Find the Light_EV_BMS_GUI.exe file inside
the AD-BMSE2E3W-SL installer files fold-
er. C:\Analog Devices\AD-BMSE2E3W-SL-Rel1.0.0\Soft-
ware\GUI\Light_EV_BMS_GUI_v1.0.0
6. Double-click the Light_EV_BMS_GUI.exe file to open the pro-
gram. You should see a script running in the background sepa-
rately and the landing page running in the browser.
7. Set the jumper configuration based on the communication
mode being used: UART or CAN.
analog.com
8. On the GUI landing page, hover to the Communication Mode
dropdown menu. Select UART COM followed by the specific
port number if using UART, or CAN if using CAN. Press the
RESET button every time the hardware set up is changed.
9. Click the Load Defaults button to set the initial entry values for
the different parameters needed for the State of Charge (SoC)
and State of Health (SoH) calculations.
10. Click the Start button to begin the measurements.
Table 2. GUI Tabs
Tabs
Overview
Graph tab
Console tab
Diagnostic tab
.
For more details on the hardware components, software controls,
and application examples, refer to the
User Guide.
Visit ADI Support
AD-BMSE2E3W-SL
Description
Features plots for stack voltage, module current, maximum
charge current, maximum discharge current, cell voltages, cell
temperatures, and state of the battery. This tab also allows
setting of the vehicle state.
Enables checking the progression of the readings for different
parameters such as the cell voltage, temperature, SoC, SoH,
and pack current.
Presents the actual numerical data being fetched by the UI in
a tabular form.
Allows to check any anomaly detected by the BMS. Some
of these diagnostic functions are cell overvoltage and
undervoltage, open-wire detection, and others. Indicators
include green equals passed (or no issue detected), and red
equals failed.
AD-BMSE2E3W-SL Wiki
for more assistance on the AD-BMSE2E3W-SL.
