3.10.4 Adjusting the Rear Wheels

CAUTION
Lack of fine adjustment of the rear wheel
Risk of falling or tipping of the user
► Check the standard adjustments of the wheelchair for stability against tipping and function of the rear wheels.
Avoid any extreme settings.
CAUTION
Incorrectly adjusted wheelbase
Risk of falling or tipping of the user
► Please note that with the rear wheel in the front position and with an unfavourable body position, the user may
tip backwards even on level ground.
► Use an anti-tipper for inexperienced users and with extreme settings of the rear wheel.
► Be sure to position the rear wheels towards the rear for transfemoral amputees. That improves the stability of
the wheelchair.
INFORMATION
Changing the rear wheel position can also change the angle between the front caster head and the ground.
However, this must be approx. 90°. The knee lever wheel lock also has to be readjusted.

3.10.4.1 Adjusting Horizontal Position of the Rear Wheels

The horizontal rear wheel position is changed by moving of the slider on the frame horizontally. This has the follow­
ing effects:
Ventus
128
130
Service Work
129
131
Ottobock | 41
