3. FUNCTION SETTING

3-1. Switching to the "Function" screen

1
In "Menu" screen, select [Function] with the [Cursor button
(Up/Down)], and press the [Enter button].
Menu
Function
Timer
Back:
Submenu
2
"Function" screen is displayed. To return to the "Menu"
screen, press the [Cancel button].
Function
Air flow direction
Economy
Set temp. auto return
Set temp. range
Back:

3-2. Function setting items

In "Function" screen, select the target function with the [Cursor
button (Up/Down)], and press the [Enter button]. Then the set-
ting screen of the selected function is displayed.
z 3-2-1. Economy setting
1
In "Function" screen, select [Economy] with the [Cursor
button (Up/Down)].
Function
Air flow direction
Economy
Set temp. auto return
Set temp. range
Back:
To change the setting, press the [Enter button].
2
Select [On] or [Off] by pressing the [Cursor button (Up/
Down)], and press the [Enter button] to complete the setting.
Function
Air flow direction
Economy
Set temp. auto return
Set temp. range
Cancel:
9381067121_OM_EN.indd 10
Mo 10:00
Setting:
Mo 10:00
Off
Disable
Disable
Setting:
Timer
Mo 10:00
Off
Disable
Disable
Setting:
Timer
Mo 10:00
On
Disable
Disable
OK:
Timer
When you return to the "Monitor" screen, the icon is displayed.
To check the function, press the [Enter button] and select the
icon with the [Cursor button (Left/Right)].
Monitor
Economy
26
Cool
End:
Menu
z 3-2-2. Set temp. auto return setting
1
In "Function" screen, select [Set temp. auto return] with
the [Cursor button (Up/Down)].
Function
Air flow direction
Economy
Set temp. auto return
Set temp. range
Back:
Setting:
To change the setting, press the [Enter button].
2
"Set temp. auto return" screen is displayed.
Set temp. auto return
Enable/Disable setting
Return time and temp. setting
Cool/Dry
Heat
Back:
Setting:
Air flow dire...
Select the item with the [Cursor button (Up/Down)], and
press the [Enter button].
3
For [Enable/Disable setting], select [Enable] or [Disable]
with the [Cursor button (Up/Down)], and press the [Enter
button] to complete the setting.
Set temp. auto return
Enable/Disable setting
Return time and temp. setting
Cool/Dry
Heat
Cancel:
OK:
Air flow dire...
Mo 10:00
° C
High
Mo 10:00
Off
Disable
Disable
Timer
Mo 10:00
Disable
Time
/
Temp.
30min.
/ /
26
° C
30min.
/
26
° C
Set temp. range
Mo 10:00
Enable
Time
/
Temp.
30min.
/ /
26
° C
30min.
/
26
° C
Set temp. range
En-10
07-Aug-15 13:40:58
