To cancel the air conditioning, set the cursor to the zone
marked with a check, and press the [Enter button] to remove
the check mark. Unchecked zone is not air-conditioned.
NOTE
• Depending on the initial setup in the installation, there is a
case that at least one zone need to be selected.
In that case, following message is displayed on the screen,
and you need to put a check mark at least one zone.
One zone must be open at all times.
XXXXXX
3
Select room-temperature sensor as follows:
Set the cursor to [Sensor] with the [Cursor button], and
press the [Enter button].
Zone ( single )
Zone 1
Zone 3
Zone 5
Zone 7
Sensor
Monitor
Select desired sensor with pressing the [Cursor button
(Up/Down)].
Zone ( single )
Zone 1
Zone 3
Zone 5
Zone 7
Sensor
Cancel:
Monitor
Each time you press the [Cursor button (Up/Down)],
displayed sensor switches as follows.
Non-connected sensor will be skipped.
Indoor unit
Primary RC
Optional 1
To complete the setting, press the [Enter button].
z 1-5-2. Zone (group) setting
Enables the simultaneous setting of zone(s) and room-
temperature sensor registered into two groups that you might
have different lifestyle; "Day" and "Night".
This setting also allows simultaneous setting to all of the con-
nected zones, as "All".
NOTE
• When "All" is selected, the room temperature sensor speci-
fied in "Sensor" of [Zone (single) setting] is applied.
For how to group the zone(s) into "Day" or "Night", refer to
"5-9-1. Day/Night setting".
9381067121_OM_EN.indd 6
XXXXXX
Mo 10:00
Zone 2
Zone 4
Zone 6
Zone 8
Indoor unit
Setting:
Zone ( group )
Mo 10:00
Zone 2
Zone 4
Zone 6
Zone 8
Indoor unit
OK:
Zone ( group )
Secondary RC
Optional 2
In "Monitor" screen, press the [Screen switch button
1
(Right)] twice.
"Zone (group)" screen opens.
Zone ( group )
Day
Night
All
On:
Zone ( single )
NOTES
• Zone(s) and room-temperature sensor grouped into "Day"
or "Night" in [Zone user setting] are displayed.
• If any names have been registered for zones and sensors
in [Zone user setting], the registered names are displayed
on this screen.
• Only zones to be air-conditioned are displayed. Undis-
played zones on this screen will not be air-conditioned.
Select the group to be air-conditioned with the [Cursor
2
button (Up/Down)], and press the [Enter button].
The group marked a check is air-conditioned.
Zone ( group )
Day
Night
All
Zone ( single )
NOTE
• The check mark currently displayed on the screen can be
unchecked only if you mark a check to the other group on
this screen, or when any setting change is done in "Zone
(single)" screen.

2. BASIC OPERATIONS

2-1. Starting the operation

PREPARATION:
Check whether the current time is displayed correctly on the
screen. When changing the time or switching the setting for
summer time (daylight saving time), follow the instructions in
"5-2. Date/Time setting".
Monitor
O f f
Menu
Mo 10:00
Zone:
Zone 1
Zone 2
Zone 3
Zone 4
Sensor:
Indoor
Monitor
Mo 10:00
Zone:
Zone 1
Zone 2
Zone 3
Zone 4
Sensor:
Indoor
Monitor
Mo 10:00
En-6
07-Aug-15 13:40:56
