2
Select [On] or [Off] with the [Cursor button (Up/Down)],
and press the [Enter button].
Filter sign
Filter sign reset
Display
Cancel:
Screen
When you set this setting to [On], and air filter cleaning on the
indoor unit is required, the icon is displayed on the "Monitor"
screen.
To check the function, press the [Enter button] and select the
icon with the [Cursor button (Left/Right)].
Monitor
Filter sign
Cool
Menu
5-5. R.C. sensor control setting
NOTE
• This function can be used only if the setting is activated in
the installation. To activate this function, consult authorized
service personnel.
1
In "Submenu" screen, select [R.C. sensor control] with
the [Cursor button (Up/Down)], and press the [Enter but-
ton].
Submenu
[
1/2
]
Date and time
Screen
Filter sign
R.C. sensor control
Room temp. display
Back:
Monitor
2
Select [On] or [Off] with the [Cursor button (Up/Down)],
and press the [Enter button].
Submenu
1/2
[
]
Date and time
Screen
Filter sign
R.C. sensor control
Room temp. display
Cancel:
Monitor
En-25
9381067121_OM_EN.indd 25
Mo 10:00
On
OK:
Initial
Mo 10:00
26
° C
High
End:
Mo 10:00
Off
Off
Setting:
Mo 10:00
On
Off
OK:
When you set this setting to [On], the icon is displayed on the
"Monitor" screen.
To check the function, press the [Enter button] and select the
icon with the [Cursor button (Left/Right)].
Monitor
R.C. sensor control
26
Cool
End:
Menu
11

5-6. Room temp. display setting

1
In "Submenu" screen, select [Room temp. display] with
the [Cursor button (Up/Down)], and press the [Enter
button].
Submenu
1/2
[
]
Date and time
Screen
Filter sign
R.C. sensor control
Room temp. display
Back:
Setting:
Monitor
2
Select [On] or [Off] with the [Cursor button (Up/Down)],
and press the [Enter button].
Submenu
[
1/2
]
Date and time
Screen
Filter sign
R.C. sensor control
Room temp. display
Cancel:
OK:
Monitor
When you set this setting to [On], the room temperature is
displayed on the screen.
Monitor
Mode
Set temp.
26
Cool
Menu
NOTE
• Displayed room temperature is the approximate temperature
detected around this remote controller, and it could be
different from the actual room temperature. It also be
influenced by the installation environment of the remote
controller.
Mo 10:00
° C
High
Mo 10:00
Off
Off
Mo 10:00
Off
On
Room 28˚
Mo 10:00
C
Fan
° C
High
07-Aug-15 13:41:11
