Lcd Display - Delta Amplon UPS102N2000B035 User Manual

NOTE :
When the backlight of the LCD is off, you can press any button mentioned
above to wake up the display and enable each button function.

3.3 LCD Display

No. Icon
1
2
3
IN
SET TEST BATT LOAD
Naming
AC Icon Indicates the input source status.
1. ON: The AC input is within the acceptable
bypass range.
2. Flashing: The AC input is out of the accep-
table bypass range but is still sufficient to let
the unit operate in on-line mode.
3. OFF: The AC input is out of the acceptable
bypass range and is not sufficient to let the
unit operate in on-line mode.
Output Icon Indicates the output status.
1. ON: There is output.
2. OFF: There is no output.
Battery Indicates the battery power status.
Power Icon
1. ON: Battery power is on.
2. OFF: Output is not supplied by the battery
power.
Chapter 3
OUT RUN TIME
Description
11
Operation Panel
!
V %
Hz
KVA
KW
MIN
°C
