- Page 1 The power behind competitiveness Delta UPS - Amplon Family MX Series, Single Phase 1.1/ 2/ 3 kVA User Manual www.deltapowersolutions.com...
- Page 2 Failure to heed these instructions and warnings will void the warranty. Copyright © 2019 by Delta Electronics Inc. All Rights Reserved. All rights of this User Manual (“Manual”), including but not limited to the contents, information, and figures are solely owned and reserved by Delta Electronics Inc.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Chapter 1 : Important Safety Warnings ------------------------------- 1 Transportation ---------------------------------------------------- 1 Preparation -------------------------------------------------------- 1 Installation --------------------------------------------------------- 1 Operation ---------------------------------------------------------- 2 Maintenance, Service and Faults --------------------------- 2 Packing List ------------------------------------------------------- 4 Chapter 2 : Installation and Setup ------------------------------------- 6 Rear Panel View ------------------------------------------------- 6 Operating principle ---------------------------------------------- 8 Install The UPS -------------------------------------------------- 8... -
Page 4: Chapter 1 : Important Safety Warnings
Connect the UPS system only to an earthed shockproof outlet which must be easily accessible and close to the UPS system. Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your computer) to connect the UPS system to the building wiring outlet (shock- proof outlet). Amplon MX Series... -
Page 5: Operation
Chapter 1 Important Safety Warnings Please use only VDE-tested, CE-marked power cables to connect the loads to the UPS system. When installing the equipment, it should ensure that the sum of the leakage cur- rent of the UPS and the connected devices does not exceed 3.5mA. Temperature Rating - Units are considered acceptable for use in a maximum ambient of 40°C (104°F). - Page 6 The likelihood of such shock can be reduced if such grounds are removed during installation and maintenance. When replacing batteries, use the same type and number of batteries or battery packs. Do not dismantle the UPS system. This is a category C1 UPS product. Amplon MX Series...
-
Page 7: Packing List
Chapter 1 Important Safety Warnings 1.6 Packing List For models UPA112M2MX0B035(1.1 kVA), UPA202M2MX0B035(2kVA), UPA302M2MX0B035(3kVA) Test report Item Q’ty 1 PC Input cable (Schuko) 1 PC USB cable 1 PC User manual 1 PC Tower stand with screws 4 PCS Ear kit with screws 2 PCS Test report 1 PC... - Page 8 For models UPA112M2MX0B0BB(1.1 kVA), UPA202M2MX0B0BB(2kVA) , UPA302M2MX0B0BB(3kVA) Test report Item Q’ty 1 PC Input cable (AU) 1 PC USB cable 1 PC User manual 1 PC Tower stand with screws 4 PCS Ear kit with screws 2 PCS Test report 1 PC Amplon MX Series...
-
Page 9: Chapter 2 : Installation And Setup
Chapter 2 Installation and Setup Chapter 2 : Installation and Setup 2.1 Rear Panel View Standard Runtime Model MX-1.1K MX-2K MX-3K... - Page 10 Programmable outlets: connect to non-critical loads. Output receptacles: connect to mission-critical loads. AC input Network/Fax/Modem surge protection Emergency power off function connector (REPO) USB communication port RS-232 communication port Mini Slot Input circuit breaker Fuse Ground screw Amplon MX Series...
-
Page 11: Operating Principle
Chapter 2 Installation and Setup 2.2 Operating principle The operating principle of the UPS is shown as below Output The UPS is composed of mains input, EMI/RFI Filters, Inverter, Battery charger, EMI / RFI Inverter Filters DC-to-DC converter, battery, AVR TX and UPS output DC - to- DC Converter Battery... - Page 12 Rack-mount Installation CAUTION : Do NOT use the mounting brackets to lift the unit. The mounting brackets are only for securing the unit to the rack. Tower Installation Step 1 Step 2 Step 3 Amplon MX Series...
-
Page 13: Setup The Ups
Chapter 2 Installation and Setup 2.4 Setup the UPS Step 1: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. The power cord is attached to the UPS. For the type of power cord, please refer to the table below. - Page 14 The REPO function logic can be set up via LCD setting. Please refer to program 7 in UPS setting for the details. It’s in closed status for To activate REPO function, UPS normal operation as default. remove these two screws. Amplon MX Series...
- Page 15 Chapter 2 Installation and Setup Step 6: Turn on the UPS Press the ON/Mute button on the front panel for two seconds to power on the UPS. NOTE : The battery charges fully during the first five hours of normal operation.
-
Page 16: Battery Replacement
This UPS is equipped with internal batteries and only service person can replace the batteries. NOTE4 : Upon battery disconnection, equipment is not protected from power outages. CAUTION!! Consider all warnings, cautions, and notes before replacing batteries. Amplon MX Series... - Page 17 Chapter 2 Installation and Setup Step 1 Step 2 Step 3 Remove front panel. Disconnect battery wires. Pull out the battery box by removing two screws on the front panel. Step 4 Step 5 Step 6 Remove the top cover of After replacing the bat- Re-connect the battery battery box and replace...
-
Page 18: Battery Kit Assembly (Option)
Then, battery kit is assem- more defect battery on the space. bly well. 4-battery kit Step 1 Step 2 Tapes Tapes Remove adhesive tapes Connect all battery terminals by follow- ing below chart. Amplon MX Series... - Page 19 Chapter 2 Installation and Setup Step 3 Step 4 Put assembled battery packs on one Cover the other side of plastic shell as side of plastic shells. below chart. Then, battery kit is assem- bly well. 6-battery kit Step 1 Step 2 Tapes Tapes...
-
Page 20: Chapter 3 : Operation
SELECT Button Setting mode: Press and hold this button for 3 seconds to enter UPS setting mode when UPS is off. Down key: Press this button to display next selection in UPS setting mode. Amplon MX Series... -
Page 21: Lcd Panel
Chapter 3 Operation Button Function Exit setting mode or return to the upper menu: When working ON/ MUTE in setting mode, press ON/Mute and Select buttons simultane- + SELECT ously for 0.2 seconds to return to the upper menu. If it’s already Buttons in top menu, press these two buttons at the same time to exit the setting mode. - Page 22 Indicates the battery is working. Indicates the bypass circuit is working. Indicates the inverter circuit is working. Indicates the output is working. Indicates the AC to DC circuit is working. Indicates the inverter circuit is working. Indicates the output is working. Amplon MX Series...
-
Page 23: Audible Alarm
Chapter 3 Operation Display Function Battery information Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%. Indicates low battery. 3.3 Audible Alarm Condition Alarm Battery Mode Sounding every 10 seconds Low Battery Sounding every 2 second Overload Sounding every second Fault Continuously sounding 3.4 LCD Display Wordings Index... - Page 24 Abbreviation Display Content Meaning Automatic / Always on Battery Low Over Load Battery No Connect Over Charge Site Fault REPO Temperature Charger Battery Fault Battery Replacement EEPROM error Amplon MX Series...
-
Page 25: Ups Setting
Chapter 3 Operation 3.5 UPS Setting There are three parameters to set up the UPS. There are two parameters to set up Parameter 2 Parameter 1 the UPS. Parameter 1: It’s for program alterna- tives. Refer to below table. Parameter 2 is the setting options or values for each program. - Page 26 03: Programmable outlets setting Parameter 2: Set up backup time limits for programmable outlets. 0-999: setting the backup time limits in minutes from 0-999 for programmable outlets which connect to non-critical devices on battery mode. (Default: 999) Amplon MX Series...
- Page 27 Chapter 3 Operation 04: Site fault detection enable/disable Parameter 2: Enable or disable site fault detection. You may choose the following two options: ENA: Site fault detection enable DIS: Site fault detection disable(Default) 05: Autonomy limitation setting Parameter 2: Set up backup time on battery mode for general outlets. 0-999: setting the backup time in minutes from 0-999 for general outlets on battery mode.
- Page 28 REPO function with Pin 1 and Pin 2 in open status. AC: Active Close. When AC is selected as REPO logic, it will activate REPO function with Pin 1 and Pin 2 in close status. 08: Input Waveform Sensitivity setting Amplon MX Series...
- Page 29 Chapter 3 Operation Parameter 2: Set Input Waveform Sensitivity. St1: Input voltage waveform detection is highly sensitive. (Default) St2: Input voltage waveform detection is middle sensitive. St3: Input voltage waveform detection is low sensitive. (use with generators or Step wave input) 09: LCD display backlight setting Parameter 2: Set up the working mode for the LCD display backlight.
-
Page 30: Operating Mode Description
Operating Mode Description Normal mode When the input voltage is within voltage regulated range, UPS will power the output directly from the mains. In this mode, when battery is fully charged, the fan will stop working for energy saving. Amplon MX Series... - Page 31 Chapter 3 Operation Buck mode when AC is normal. When the input voltage is higher than the voltage regulation range but lower than high loss point, the buck AVR will be activated. Boost mode when AC is normal. When the input voltage is lower than the voltage regulation range but higher than low loss point, the boost AVR will be activated.
-
Page 32: Faults Reference Code
3.8 Warning Indicator Warning Icon (flashing) Code Alarm Low battery Sounding every 2 seconds Overload Sounding every second Battery is not Sounding every 2 seconds connected Over charge Sounding every 2 seconds Site wiring fault Sounding every 2 seconds Amplon MX Series... - Page 33 Chapter 3 Operation Warning Icon (flashing) Code Alarm REPO enable Sounding every 2 seconds Over Sounding every 2 seconds temperature Charger failure Sounding every 2 seconds Battery fault Sounding every 2 seconds (At this time, UPS is off to Battery remind users something wrong replacement with battery)
-
Page 34: Chapter 4 : Troubleshooting
27 on LCD display and or the charger is fault. alarm is continuously sounding. Fault code is shown as Battery voltage is too low or Contact your dealer. 28 on LCD display and the charger is fault. alarm is continuously sounding. Amplon MX Series... - Page 35 Chapter 4 Troubleshooting Symptom Possible Cause Remedy UPS is overload Remove excess loads The icon from UPS output. the warning code flashing on LCD display and alarm is sounding every second. Fault code is shown as The UPS shut down auto- Remove excess loads 43 and the icon matically because of over-...
-
Page 36: Chapter 5 : Storage And Maintenance
During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration -25°C ~ 40°C Every 3 months 1 ~ 2 hours 40°C ~ 45°C Every 2 months 1 ~ 2 hours Amplon MX Series... -
Page 37: Chapter 6 : Technical Specifications
Chapter 6 Technical Specifications Chapter 6 : Technical Specifications Model MX-1.1K MX-2K MX-3K Capacity 1100VA / 990W 2000 VA / 1800 W 3000VA / 2700W Input 200V: 150-234V / 208V: 156-243V / 220V: 162-268V Voltage Range / 230V: 170-280V / 240V: 177-290V Frequency Range 50/60 Hz (auto sensing) Connection... - Page 38 RS-232 Port x 1, USB Port x 1, MINI Slot x 1, Interface Surge Protection, REPO NOTE : 1. *Derate to 85% of capacity when the output voltage is adjusted to 200/208VAC. 2. Product specifications are subject to change without further notice. Amplon MX Series...
-
Page 39: Chapter 7 : Warranty
Chapter 7 Warranty Chapter 7 : Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship within the warranty period. If the product has any failure problem within the warranty period, Seller will repair or replace the product at its sole discretion according to the failure situation. - Page 40 Version Date : 2019_06_19...
