Delta Amplon UPS102N2000B035 User Manual page 19

No. Icon
4 SET
5 TEST
6 BATT
7 LOAD
Description
When the word 'SET' illuminates, it means that the UPS is in
the setup mode.
You can set up the following items via the LCD. For how to
setup, please refer to 5.5 Setup Mode.
1. Inverter voltage
2. Inverter frequency
3. Bypass range
4. Buzzer disable
5. Overload alarm
1. When the word 'TEST' flashes, it means that the UPS is
under test.
2. When the two words 'TEST' and 'BATT' flash together, it
means that the UPS is under battery test.
1. BATT & %:
When the above two words illuminate together, it means
the remaining battery capacity.
2. BATT & V:
When the above two words illuminate together, it means
battery voltage.
1. LOAD & %:
When the above two words illuminate together, it means
how much the total load has occupied the rated capacity.
2. LOAD & KVA:
When the above two words illuminate together, it means
how much kVA the total load is.
3. LOAD & KW:
When the above two words illuminate together, it means
how much kW the total load is.
4. LOAD & % &
When the above word (LOAD), unit (%) and icon
together, it means that the UPS has an overload situation.
Chapter 3
:
1 5
Operation Panel
flash
