No. Icon
4
5
6
7
8
9
Amplon N Series
Naming
Standby Illuminates when the UPS is operating in stand-
Mode Graph by mode.
Online Mode Illuminates when the UPS is operating in on-line
Graph mode.
Battery Illuminates when the UPS is operating in battery
Mode Graph mode.
Bypass Illuminates when the UPS is operating in bypass
Mode Graph mode.
Buzzer Icon Illuminates when the buzzer is disabled.
Warning Icon 1. ON:
Description
The unit is shut down due to an internal fault
or an environmental fault. The error code will
appear on the 7-segment display. Please refer
to the following table for each error code and
refer to 3.4 7-Segment Display for relevant
7-segment display information.
Error Code Meaning
E11 Charger Fault
E13 Temperature Out of Range
E14 +/- DC BUS High/ Low
E16 Inverter Fault
E18 DC-DC Fault
E19 Abnormal Output/ Inverter
Voltage
E21 O/P Short
Sd1 RPO Shutdown
Sd4 Battery Low Shutdown
