The computer cannot receive or transmit data until the computer and
applications are fully running. Thus, connection cannot be made on the
first try. Turning an external modem off and then back on while the
computer is off causes an initialization string that turns the system
power on.
Power On By RTC Alarm [Disabled]
Allows you to enable or disable RTC to generate a wake event. When this
item is set to Enabled, the items RTC Alarm Date, RTC Alarm Hour, RTC
Alarm Minute, and RTC Alarm Second appear with set values.
Configuration options: [Disabled] [Enabled]
2.5.5
Hardware Monitor
Hardware Monitor
CPU Temperature
MB Temperature
CPU Fan Speed
Chassis Fan Speed
Power Fan Speed
VCORE Voltage
3.3V Voltage
5V Voltage
12V Voltage
Smart Q-FAN Function
CPU Temperature [xxx ºC/xxx ºF]
MB Temperature [xxx ºC/xxx ºF]
The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures.
CPU Fan Speed [xxxxRPM] or [N/A]
Chassis Fan Speed [xxxxRPM] or [N/A]
The onboard hardware monitor automatically detects and displays the CPU
and chassis fan speeds in rotations per minute (RPM). If any of the fans is
not connected to the motherboard, the specific field shows N/A.
2-30
[40.5ºC/102.5ºF]
[33ªC/91ºF]
[3260RPM]
[N/A]
[N/A]
[ 1.408V]
[ 3.360V]
[ 5.160V]
[11.328V]
[Disabled]
CPU Temperature
Chapter 2: BIOS Setup
