9.
Front panel audio connector (10-1 pin FP_AUDIO)
This connector is for a chassis-mounted front panel audio I/O module
that supports legacy AC '97 audio standard. Connect one end of the
front panel audio I/O module cable to this connector.
M2S-X
R
M2S-X Front panel audio connector
10. System panel connector (10-1 pin PANEL)
This connector accommodates several system front panel functions.
M2S-X
R
M2S-X System Panel Connector
1-28
FP_AUDIO
PLED
PANEL
IDE_LED
Chapter 1: Product introduction
SPEAKER
Reset
PWRSW
