M2S-X specifications summary

CPU
Chipset
System bus
Memory
Expansion slots
Storage
LAN
Audio
USB
ASUS special features
Rear panel
x
Socket AM2 for AMD Athlon™ 64 FX/AMD Athlon™ 64 X2
/AMD Athlon 64™/AMD Sempron™ processors
Supports AMD Cool 'n' Quiet™ Technology
AMD64 architecture enables simultaneous 32-bit and
64-bit computing
AMD Live!™ ready
SIS® 756
SIS® 965L
2000 / 1600 MT/s
Dual-channel memory architecture
- 4 x 240-pin DIMM sockets support unbuffered
ECC/non-ECC DDR2 800/667/533 MHz memory
modules
- Supports up to 4 GB system memory
1 x PCI Express™ x16 slot
2 x PCI Express™ x1 slots
3 x PCI 2.2 slots
2 x Ultra DMA 133/100/66/33
2 x SATA support RAID 0, 1, and JBOD
Realtek RTL8201CL 10/100 LAN
®
C-Media Superior Quality Audio 7.1 channel audio
CODEC
Supports S/PDIF Out interface
Supports up to 6 USB 2.0 ports (two at mid-board, four on
the rear panel)
ASUS C.P.R.
ASUS MyLogo
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS Q-Fan
SFS (Stepless Frequency Selection) from 200MHz up to
400MHz at 1MHz increment
1 x Parallel port
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x Serial port
1 x S/PDIF Out port (Coaxial)
1 x LAN (RJ-45) ports
4 x USB 2.0/1.1 ports
8-channel audio I/O ports
(continued on the next page)
