Asus Motherboard M2S-X User Manual page 11

M2S-X specifications summary
Internal connectors
BIOS features
Manageability
Accessories
Support CD contents
Form factor
*Specifications are subject to change without notice.
1 x USB 2.0 connector supports additional 2 USB 2.0
ports
1 x Floppy disk drive connector
2 x IDE connector
2 x Serial ATA connectors
1 x CPU fan / 1 x Chassis fan
1 x Chassis intrusion connector
1 x S/PDIF out header connector
Front panel audio connector
CD audio in connectors
24-pin ATX power connector
4-pin ATX 12 V power connector
System panel connector
4 Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM2.0, SM
BIOS 2.3, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
UltraDMA cable
FDD cable
SATA cable
SATA power cable
I/O Shield
User's maual
Drivers
ASUS PC Probe II
ASUS Update
Anti-virus software (OEM version)
ATX form factor: 12 in x 8.6 in (30.5 cm x 21.8 cm)
1
xi
