5. Installing the Scanner ICC Profiler

Note: The Scanner ICC Profiler program should have
been installed at the time you performed software
installation procedures (discussed earlier in the manual).
If for some reason you have not installed the Scanner
ICC Profiler, follow the steps below to install the
program.
A. For the Macintosh
Before installing the Scanner ICC Profiler, you should
have ScanWizard Pro and the Kodak CMS programs
installed on your computer.
To install the Scanner ICC Profiler program: Insert the
Artix CD into your CD-ROM drive. Open the ICC
Profiler folder, then double-click the Installer icon to
install the program.
B. For Windows 98 / 95 / NT 4.0
Before installing the Scanner ICC Profiler, you should
have ScanWizard Pro and the Kodak CMS programs
installed on your computer.
To install the Scanner ICC Profiler program: Insert the
Artix CD into your CD-ROM drive. When the Software
Installer screen appears, click on the "Install" option for
the Scanner ICC Profiler program, then follow the on-
screen instructions until the program finishes installing.
26 ArtixScan 1100 Hardware User's Guide

6. Placing the color target

• Positioning the target in the upper bed: Place the
reflective color target in the upper scan bed and make
sure it is positioned correctly, following the
illustration below. See the additional notes in the next
section for important notes on how to position the
reflective target correctly on the upper bed. Then
proceed to the calibration procedures discussed in the
succeeding pages to calibrate the upper scan bed.
• Positioning the target in the lower bed: After
completing the entire calibration process for the
upper bed (detailed in the next few pages), return to
this section to see how to position the transparency
target correctly on the lower scan bed. Then proceed
again to the calibration procedures discussed in the
next pages to calibrate the lower scan bed.
Positioning the target on the upper scan bed
Positioning the target on the lower scan bed. In
the example above, the target is placed in the 4"
x 5" Film Holder, and the Holder is then placed
into the transparency tray of the lower scan bed.
