V I . C O M F O R T A D J U S T M E N T S
TILLER ANGLE ADJUSTMENT
WARNING! Remove the key from the
key switch before adjusting the tiller
or the seat. Never attempt to adjust
the tiller or the seat while the
scooter is in motion.
Your scooter is equipped with an adjustable pivoting
tiller.
1. Squeeze the tiller adjustment lever. See figure 16.
2. Move the tiller to a comfortable position.
3. Release the tiller adjustment lever.
NOTE: In order to fully lower the tiller for purposes
of disassembly or transport, you must first com-
pletely remove the seat.
MIRROR POSITION
To install the mirror (see figure 17):
1. Determine on which side to install the mirror and
remove the rubber plug from the top of the tiller
handle.
2. Insert the threaded end of the mirror holder into
the opening and rotate it clockwise until snug.
3. If necessary, rotate the nut clockwise to secure
the mirror in place.
To adjust the mirror:
1. Position yourself in a seated driving position fac-
ing forward.
2. Adjust the mirror left, right, up or down until you
have a good line of sight behind you.
SEATBACK ADJUSTMENT
WARNING!
scooter with the seatback in a
reclined position.
WARNING! Always keep your back
pressed firmly against the seatback
while adjusting the angle.
To adjust your scooter's reclining seat, perform these
steps. See figure 18.
1. With your back pressed up against the seatback,
lift up on the seatback adjustment lever and lean
forward or rearward to adjust the seatback angle.
2. Release the seatback adjustment lever once the
seat is in a comfortable riding position.
Colt Executive
Do
not
operate
your
www.pridemobility.com
TILLER ADJUSTMENT LEVER
Figure 16. Tiller Adjustment
MIRROR HOLDER
NUT
Figure 17. Mirror Installation and Positioning
Figure 18. Seatback Adjustment
RUBBER PLUG
SEATBACK
ADJUSTMENT
LEVER
31
