V I . C O M F O R T A D J U S T M E N T S
POSITIONING BELT (OPTIONAL)
Your scooter seat may be equipped with an auto-type
positioning belt that can be adjusted for operator
comfort. The positioning belt is designed to help sup-
port the operator so that he or she does not slide down
or forward in the seat. The positioning belt is not
designed for use as a restraining device.
To install the positioning belt (if required):
1. Remove the seat from your scooter.
2. Place the seat upside down so that you can see the
bottom of the seat base. See figure 21.
3. Use a spanner to remove the two back bolts on the
outermost part of the rear seat.
4. Insert the bolt through the appropriate ends of the
positioning belt and then reinstall the bolts and
belt back into the seat bottom.
5. Tighten the bolts.
To adjust the positioning belt for operator comfort:
1. Insert the metal tab on the right side of the belt into the plastic housing on the opposite strap until you
hear a "click." See figure 21.
2. Pull the strap on the right side of the belt until it is secure, but not so tight as to cause discomfort.
To release the positioning belt:
1. Press the push button mechanism on the plastic housing.
MANDATORY! Make sure the positioning belt is properly secured to the scooter and is
adjusted for operator comfort before each use.
MANDATORY! Inspect the positioning belt for loose or damaged parts before each use of
the scooter. If you discover a problem, contact your authorised Pride Dealer for mainte-
nance and repair.
Colt Executive
Figure 21. Positioning Belt
www.pridemobility.com
33
