  • Page 1 T 3 x - 0 5 T r e a d m i l l S e r V i C e m a N U a l...

  • Page 2: Table Of Contents

    Table of CoNTeNTS CHaPTer 1: Serial NUmber loCaTioN ............1 CHaPTer 2: imPorTaNT SafeTy iNSTrUCTioNS Before Getting Started ....................2 Read and Save These Instructions ................3 Electrical Requirements ..................... 4 CHaPTer 3: PreVeNTaTiVe maiNTeNaNCe Recommended Cleaning Tips ..................5 Check for Damaged Parts ..................
  • Page 3 Table of CoNTeNTS CHaPTer 9: ParT rePlaCemeNT GUide Motor Cover Replacement ....................32 Rear Roller Replacement ....................33 Side Rail Replacement ....................34 Running Deck Replacement ..................35 Deck Cushion Replacement ................... 36 Front Roller Replacement ....................37 Running Belt Removal ....................38 Motor Control Board (MCB) Replacement ..............

  • Page 4: Chapter 1: Serial Number Location

    CHaPTer 1: Serial NUmber loCaTioN 1.1 Serial NUmber loCaTioN CoNSole Serial NUmber loCaTioN frame Serial NUmber loCaTioN...

  • Page 5: Chapter 2: Important Safety Instructions

    CHaPTer 2: imPorTaNT SafeTy iNSTrUCTioNS 2.1 before GeTTiNG STarTed This treadmill is intended for commercial use. To ensure your safety and protect the equipment, read all instructions before operating the Matrix Treadmill. LOCATION OF THE TREADMILL Place the treadmill on a level and stable surface away from direct sunlight. The intense UV light can cause discoloration on the plastics. Locate your treadmill in an area with cool temperatures and low humidity.

  • Page 6: Read And Save These Instructions

    When using an electrical product, basic precautions should always •   D onotusetheequipmentinanywayotherthandesignedor be followed including the following: intended by the manufacturer. It is imperative that all Matrix Fitness System's equipment is used properly to avoid injury. daNGer: To reduce the risk of electric shock: always unplug this equipment from the electrical outlet immediately after • Keephandsandfeetclearofmovingpartsatalltimestoavoid...

  • Page 7: Electrical Requirements

    TV PoWer reqUiremeNTS If a TV will be added to the treadmill via a bracket, separate power must be provided for the TV. Matrix TVs require the use of a 15 amp or 20 amp “dedicated circuit,” with a non-looped (isolated) neutral / ground, for the power requirement. Up to 12 TVs can be daisy chained per 15...

  • Page 8: Chapter 3: Preventative Maintenance

    3.2 CHeCk for damaGed ParTS do NoT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems. maiNTaiN labelS aNd NamePlaTeS. Do not remove labels for any reason. They contain important information. If unreadable or missing, contact Matrix Fitness Systems for a replacement at 866-693-4863 or www.matrixfitness.com.

  • Page 9: Preventative Maintenance Instructions

    3.3 PreVeNTaTiVe maiNTeNaNCe iNSTrUCTioNS In order to maximize life span, and minimize down time, all Matrix Fitness System's equipment requires regular cleaning, and maintenance items performed on a scheduled basis. This section contains detailed instructions on how to perform these items and the frequency of which they should be done.

  • Page 10: Auto Calibration Procedure

    CHaPTer 3: PreVeNTaTiVe maiNTeNaNCe 3.4 aUTo CalibraTioN iNSTrUCTioNS 3.5 adjUSTiNG THe rUNNiNG belT Run Auto Calibration to calibrate incline after assembly and after After placing the treadmill in the position it will be used, the belt replacing any electronic component. must be checked for proper tension and centering.

  • Page 11: Console Description

    CHaPTer 4: CoNSole oVerlay aNd WorkoUT deSCriPTioN 4.1 T3x-05 CoNSole deSCriPTioN WorkoUT keyS: Simple program view and selection buttons. Press Fitness Test button to cycle through available tests. Go: One Touch Start. eNTer: To confirm each program setting. UP / doWN iNCliNe: Adjust incline and make program selections.

  • Page 12: Manual Workout Operation

    4.3 leVel baSed WorkoUT oPeraTioN Your Matrix T3x-05 Treadmill offers a variety of level-based workouts to challenge users of all fitness levels. The following information will briefly explain the workouts and how to program the treadmill for each workout selection.

  • Page 13: Heart Rate Control Workout Operation

    4.5 fiTNeSS TeST WorkoUT oPeraTioN Your Matrix T3x-05 Treadmill offers a variety of fitness tests - the Gerkin Firefighter Protocol, the Wellness Fitness Initiative (WFI), the Army, Navy, USMC, and USAF as well as the Physical Efficiency Battery (PEB).
  • Page 14 CHaPTer 4: CoNSole oVerlay aNd WorkoUT deSCriPTioN 4.5 fiTNeSS TeST WorkoUT oPeraTioN - CoNTiNUed CardioVaSCUlar fiTNeSS PerCeNTileS SUb maximal Treadmill eValUaTioN CoNVerSioN Table males: Vo2 max (ml/kg/min) 0-29 30-39 40-49 50-59 Stage Time Converted Vo2max >58.8 >58.9 >55.4 >52.5 1:00 31.15 SUPERIOR 1:15...

  • Page 15: Chapter 5: Manager Mode

    CHaPTer 5: maNaGer mode 5.1 USiNG maNaGer mode 1) To enter Manager Mode, press & hold INCLINE DOWN and SPEED DOWN keys at the same time for 3-5 seconds until Manager appears on the display. 2) To enter the Manager Mode, press ENTER once Manager Mode appears on the display (Figure A).

  • Page 16: Chapter 6: Engineering Mode

    CHaPTer 6: eNGiNeeriNG mode 6.1 USiNG eNGiNeeriNG mode 1) To enter Engineering Mode, press & hold the INCLINE DOWN and SPEED DOWN keys at the same time for 3-5 seconds until Manager Mode appears on the display. 2) Press the INCLINE or SPEED keys until Engineering Mode appears on the display (Figure A) and press ENTER.

  • Page 17: Chapter 7: Service Mode

    CHaPTer 7: SerViCe mode 7.1 USiNG SerViCe mode 1) To enter Service Mode, press & hold the INCLINE DOWN and SPEED DOWN keys at the same time for 3-5 seconds until Manager Mode appears on the display. 2) Press the INCLINE or SPEED keys until Service Mode appears on the display (Figure A) and press ENTER.

  • Page 18: Chapter 8: Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.1 eleCTriCal diaGramS...
  • Page 19 CHaPTer 8: TroUbleSHooTiNG 8.1 eleCTriCal diaGramS - CoNTiNUed diGiTal CommUNiCaTioN Wire GriP SeNSor Wire...
  • Page 20 CHaPTer 8: TroUbleSHooTiNG 8.1 eleCTriCal diaGramS - CoNTiNUed H/P Wire keyPad Wire...

  • Page 21: Mcb Wiring

    CHaPTer 8: TroUbleSHooTiNG 8.2 mCb WiriNG jP3 - Console Cable jP4 - incline motor Cable N - Power input (white) l - Power input (black) U - motor Wire (red) V - motor Wire (White) W - motor Wire (black) aC 110V : j1 and j4 Short aC 220V : j1 and j4 open...

  • Page 22: Mcb Led Placement And Definitions

    CHaPTer 8: TroUbleSHooTiNG 8.3 mCb led PlaCemeNT aNd defiNiTioNS PWm - Console PWm signal light (when the motor is running, the light should flash). Com - digital communication light. faUlT - The machine has stopped due to any C class error. UP / doWN (ff) - incline motor status light.

  • Page 23: 0140 / 01A0 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.4 0140 / 01a0 error TroUbleSHooTiNG error meSSaGe 0140 / 01a0 1) causE: a. 0140 – Incline motor operation failure. b. 01A0 – Incline motor disconnection. 2) sOLuTION: a. Check the incline motor wire connection between the incline motor and MCB (Figure A). b.

  • Page 24: 01A4 / 01A5 / 01A6 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.5 01a4 / 01a5 / 01a6 error TroUbleSHooTiNG error meSSaGe 01a4 / 01a5 / 01a6 1) causE: a. 01A4 - Main motor U phase disconnection. b. 01A5 - Main motor V phase disconnection. c. 01A6 - Main motor W phase disconnection. 2) sOLuTION: a.

  • Page 25: 01A8 / 01Ad / 02B6 / 02B7 / 02B8 Error Troubleshooting

    02B8 - Running status over current. 2) sOLuTION: a. Perform an amp draw (see instruction for how to run an amp draw on Matrix treadmills). Flip the deck or replace the running belt as needed. b. If the amp draw is normal, replace the MCB.

  • Page 26: 01Ab Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.7 01ab error TroUbleSHooTiNG error meSSaGe 01ab 1) causE: a. Inverter error. 2) sOLuTION: a. When the display is showing an 01AB error, the MCB Fault LED should be lit (Figure A). b. If the MCB Fault LED is not lit, replace the console. c.

  • Page 27: 02A0 / 02A8 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.8 02a0 / 02a8 error TroUbleSHooTiNG error meSSaGe 02a0 / 02a8 1) causE: a. 02A0 - Main motor failure. The belt does not move when it is supposed to move. b. 02A8 - Inverter circuit of the motor failed. Motor resistance is closed. 2) sOLuTION: a.

  • Page 28: 02A1 / 02A2 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.9 02a1 / 02a2 error TroUbleSHooTiNG error meSSaGe 02a1 / 02a2 1) causE: a. 02A1 - Over AC power input voltage. b. 02A2 - Over / low DC bus voltage. 2) sOLuTION: a. Use a multi - meter to check if the input power matches local power specifications at the MCB. Switch to a different outlet if necessary. - If a known good outlet is not providing the correct power, replace the power components as needed.

  • Page 29: 02Ad Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.10 02ad error TroUbleSHooTiNG error meSSaGe 02ad 1) causE: a. MCB over temperature. 2) sOLuTION: a. Check the Motor wire connection between the Motor and MCB (Figure A). b. Use a multi meter to check the for a resistance value across the 2 blue wires of the motor wire (Figure B). -- If there is a resistance value, replace the MCB.

  • Page 30: 02B5 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.11 02b5 error TroUbleSHooTiNG error meSSaGe 02b5 1) causE: a. The inverter sensor is reading the normal rated current is over 10.5 amps for 60 seconds. 2) sOLuTION: a.Useamulti-metertocheckthe3points(U/V/W)ofthemotorcableforresistanceover4Ω(FiguresA,b&C). -- If yes, replace the motor. -- If no, flip the deck and / or replace the running belt. b.

  • Page 31: 02B9 / 02Ba / 02Bc / 02Bd Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.12 02b9 / 02ba / 02bC / 02bd error TroUbleSHooTiNG error meSSaGe 02b9 / 02ba / 02bC / 02bd 1) causE: a. 02B9 - The inner memory IC data write error. b. 02BA - The inner memory IC data read error. c.

  • Page 32: 04A0 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.13 04a0 error TroUbleSHooTiNG error meSSaGe 04a0 1) causE: a. PCB communication disconnected. 2) sOLuTION: a. Check the console cable connection between the UCB and MCB (Figures A & B). b. Replace the console cable if any damage is found. c.

  • Page 33: 04B0 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.14 04b0 error TroUbleSHooTiNG error meSSaGe 04b0 1) causE: a. MCB communication disconnected. 2) sOLuTION: a. Check the console cable connection between the UCB and MCB (Figures A & B). b. Replace the console cable if any damage is found. c.

  • Page 34: Troubleshooting Heart Rate Issues

    HR handlebar). If the ohm reading is correct, your issue is not with the HR grip / HR wire portion of the HR system. b. Perform a continuity test on the treadmill console (see Service Bulletin - Continuity Test on Matrix Treadmills).

  • Page 35: Chapter 9: Part Replacement Guide

    CHaPTer 9: ParT rePlaCemeNT GUide 9.1 moTor CoVer rePlaCemeNT 1) Remove the 2 screws holding the motor cover to the frame using a 6 mm Allen wrench (Figures A). 2) The motor cover is secured to the frame with velcro, so you will have to pull up with some force (Figure B). fiGUre a fiGUre b 3) Figure C shows the motor area with the cover removed.

  • Page 36: Rear Roller Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.2 rear roller rePlaCemeNT 1) Remove one of the rear end caps using a Phillips screwdriver (Figure A). 2) Remove both roller adjustment screws using an 8 mm Allen wrench (Figure B). fiGUre a fiGUre b 3) Remove the rear roller from the running belt (Figures C &...

  • Page 37: Side Rail Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.3 Side rail rePlaCemeNT 1) Remove the rear end cap using a Phillips screwdriver (Figure A). 2) Loosen the four screws under the frame using a 5 mm Allen wrench (Figure B). fiGUre a fiGUre b 3) Slide the rail off the back of the treadmill (Figures C &...

  • Page 38: Running Deck Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.4 rUNNiNG deCk rePlaCemeNT 1) Remove the motor cover as outlined in Section 9.1. 2) Remove the side rail as outlined in Section 9.3. 3) Remove the four running deck screws using a 5 mm Allen wrench (Figure A). fiGUre a 4) Remove the running deck from the running belt (Figures B &...

  • Page 39: Deck Cushion Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.5 deCk CUSHioN rePlaCemeNT 1) Remove the deck as outlined in Section 9.4. 2) Holding the bolt with a 5 mm Allen wrench, loosen the nut with a 13 mm socket (Figure A & B). fiGUre a fiGUre b 3) For the rear cushion, hold the cushion and remove the 13 mm nut (Figure C).

  • Page 40: Front Roller Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.6 froNT roller rePlaCemeNT 1) Remove the motor cover as outlined in Section 9.1. 2) Loosen both of the rear roller screws using an 8mm T-Shaped wrench to remove tension from the running belt (Figure A). 3) Remove the front roller mounting screws using an 6 mm Allen wrench (Figures B &...

  • Page 41: Running Belt Removal

    CHaPTer 9: ParT rePlaCemeNT GUide 9.7 rUNNiNG belT rePlaCemeNT 1) Remove the motor cover as outlined in Section 9.1. 2) Remove the rear roller as outlined in Section 9.2. 3) Remove the running deck as outlined in Section 9.4. 4) Remove the front roller as outlined in Section 9.6. 5) Remove the running belt (Figures A).

  • Page 42: Motor Control Board (Mcb) Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.8 moTor CoNTrol board (mCb) rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the motor cover as outlined in Section 9.1. 3) Disconnect the wire connectors at the MCB. 4) Remove the 2 screws holding each side of the MCB to the frame (Figures A &...

  • Page 43: Motor Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.9 moTor rePlaCemeNT 1) Turn off power to the treadmill and disconnect the power cord. 2) Remove the motor cover as outlined in Section 9.1. 3) Use a hook or loop of wire to remove the spring from the drive belt tensioner (Figure A). 4) Remove the drive belt tensioner using a 6 mm Allen wrench (Figure B) fiGUre b fiGUre a...
  • Page 44 CHaPTer 9: ParT rePlaCemeNT GUide 9.9 moTor rePlaCemeNT - CoNTiNUed 7) Disconnect the motor cable from the MCB (Figure E). 8) Remove the 4 screws holding the motor to the frame (Figure F). 9) Remove the motor from the treadmill. fiGUre e fiGUre f 10) Reverse Steps 1-9 to install a new motor.

  • Page 45: Drive Belt Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.10 driVe belT rePlaCemeNT 9.10 driVe belT rePlaCemeNT 1) Turn off power to the treadmill and disconnect the power cord. 2) Remove the motor cover as outlined in Section 9.1. 3) Use a hook or loop of wire to remove the spring from the drive belt tensioner (Figure A). 4) The tensioner should now pivot away from the drive belt (Figure B) fiGUre a fiGUre b...
  • Page 46 CHaPTer 9: ParT rePlaCemeNT GUide 9.10 driVe belT rePlaCemeNT - CoNTiNUed 7) Remove the two 8 mm screws from front roller (Figures E & F). fiGUre e fiGUre f 8) Lift the roller and remove the old drive belt (Figure G). fiGUre G 9) Reverse Steps 1-8 to install a new drive belt.

  • Page 47: Incline Motor Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.11 iNCliNe moTor remoVal 1) Turn off power to the treadmill and disconnect the power cord. 2) Remove the motor cover as outlined in Section 9.1. 3) Lift the treadmill and support it so that the front wheels are off the floor, or the unit may be tipped on its side (Figure A). 4) Remove the cotter pin from the elevation rack pin (Figure B).
  • Page 48 CHaPTer 9: ParT rePlaCemeNT GUide 9.11 iNCliNe moTor rePlaCemeNT - CoNTiNUed 7) Remove the incline motor cable ground wire from the ground prong in the motor frame (Figure E). 8) Disconnect the incline motor from the top mounting bracket (Figure F). fiGUre e fiGUre f 9) Lift the incline motor away from the treadmill (Figure G).

  • Page 49: Console Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.12 CoNSole rePlaCemeNT 1) Turn off power to the treadmill and disconnect the power cord. 2) Remove the 2 screws holding the back cover onto the console (Figure A). 3) Remove the 4 screws holding the console onto the console frame (Figure B). fiGUre a fiGUre b 4) Disconnect the 6 wire connections from the console (Figure C).

  • Page 50: Emergency Stop Switch Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.13 emerGeNCy SToP SWiTCH rePlaCemeNT 1) Turn off power to the treadmill and remove the power cord. 2) Remove the console as outlined in Section 9.12. 3) Remove the 2 screws holding the emergency stop key to the emergency stop frame (Figure A). 4) Remove the 2 screws holding the emergency stop frame to the console frame (Figure B).
  • Page 51 CHaPTer 9: ParT rePlaCemeNT GUide 9.13 emerGeNCy SToP SWiTCH rePlaCemeNT - CoNTiNUed 6) Disconnect the 2 wires plugged into the back of the emergency stop switch (Figure E). 7) Depress the tabs on the top and the bottom of the emergency stop switch (Figure F). fiGUre f fiGUre e 8) Once the tabs are depressed, the emergency stop can be removed from the emergency stop frame (Figure G).

  • Page 52: Cup Holder Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.14 CUP Holder rePlaCemeNT 1) Remove the console as outlined in Section 9.12. 2) Remove the 3 screws holding the cup holder to the console frame (Figure A & B) fiGUre b fiGUre a 3) Remove the cup holder (Figure C). fiGUre C 4) Reverse Steps 1-3 to install a new cup holder.

  • Page 53: Console Frame Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.15 CoNSole frame rePlaCemeNT 1) Turn off power to the treadmill and disconnect the power cord. 2) Remove the console as outlined in Section 9.12. 3) Remove the 2 screws on each side holding the console frame to the handlebar frame (Figure A). 4) Remove the 3 screws on each side holding the cup holder to the console frame (Figure B) fiGUre b fiGUre a...
  • Page 54 CHaPTer 9: ParT rePlaCemeNT GUide 9.15 CoNSole frame rePlaCemeNT - CoNTiNUed 7) Remove the console frame (Figure E). fiGUre e 8) Reverse Steps 1-7 to install a new console frame. 9) Test the treadmill for function as outlined in Section 9.21.

  • Page 55: Heart Rate Board Service

    CHaPTer 9: ParT rePlaCemeNT GUide 9.16 HearT raTe board rePlaCemeNT 1) Turn off power to the treadmill and remove the power cord. 2) Remove the console as outlined in Section 9.12. 3) Disconnect the wire connections that go to the heart rate board (Figure A & B). fiGUre a fiGUre b 4) Depress the 4 spacer supports holding the heart rate board to the console frame and remove it (Figure C).

  • Page 56: Handlebar Frame Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.17 HaNdlebar frame rePlaCemeNT 1) Turn off power to the treadmill and remove the power cord. 2) Remove the console as outlined in Section 9.12. 3) Remove the console frame as outlined in Section 9.15 4) Remove the 3 screws on each side holding the handlebar frame to the console mast (Figure A).

  • Page 57: Heart Rate Handlebar Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.18 HearT raTe HaNdlebar rePlaCemeNT 1) Turn off power to the treadmill and remove the power cord. 2) Remove the console as outlined in Section 9.12. 3) Remove the console frame as outlined in Section 9.15. 4) Remove the 3 screws on each side holding the handlebar frame to the console mast (Figure A).

  • Page 58: Heart Rate Grips Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.19 HearT raTe GriPS rePlaCemeNT 1) Turn off power to the treadmill and remove the power cord. 2) Remove the 2 Phillips screws holding the 2 halves of the HR grip together (Figure A). 3) Disconnect the white wire from the bottom HR terminal and remove it (Figure B). fiGUre b fiGUre a 4) Disconnect the red wire from the top HR terminal and remove it (Figure C).

  • Page 59: Console Mast Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.20 CoNSole maST rePlaCemeNT 1) Turn off power to the treadmill and remove the power cord. 2) Remove the console as outlined in Section 9.12. 3) Remove the console frame as outlined in Section 9.15. 4) Remove the handlebar frame as outlined in Section 9.17.

  • Page 60: Testing The Treadmill

    CHaPTer 9: ParT rePlaCemeNT GUide 9.21 TeSTiNG THe Treadmill oNCe THe Treadmill or rePlaCemeNT ParT iS fUlly iNSTalled aNd aSSembled aNd ProPerly PlaCed oN THe floor, USe THe folloWiNG iNSTrUCTioNS To SeTUP aNd TeST THe maCHiNe: 1) If the treadmill was just assembled or if any electronic component has been replaced (including if the console cable is unplugged for any reason), the treadmill MUST be auto calibrated.

  • Page 61: Chapter 10: Treadmill Specifications And Assembly Guide

    INCLINE RANGE 0%-15%(1,300Lb/589.7KGTHRUSTINCLINEMOTOR) SPEED RANGE 0.5-12.0MPH/0.8-20KPH CONTACT & TELEMETRIC HR SENSORS DRIVE SYSTEM MOTOR MATRIX 4.2 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MOTOR CONTROLLER COMMERCIAL TREADMILL AC DRIVE CONSOLE DISPLAY TYPE DOT-MATRIX LED DISPLAYFEEDbACK TIME, TIME ELAPSED, TIME REMAINING, TOTAL PROGRAM TIME,...

  • Page 62: Fasteners And Assembly Tools

    CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.2 faSTeNerS aNd aSSembly ToolS frame SeT CoNSole SeT ParT # ParT Name diaGram SPeCifiCaTioN qUaNTiTy Color Hex Head Cap Screw M8 x 1.25P x 40L Yellow...

  • Page 63: Assembly Instructions

    Prior to assembling the treadmill, unpack all of the contents of the box and make sure that all necessary components are present. Review the contents of the hardware package for completeness. Contact Matrix customer service at 866.693.4863 to report any missing items.
  • Page 64 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.3 aSSembly iNSTrUCTioNS - CoNTiNUed STeP 3 Open YELLOW AND WHITE HARDWARE BAGS. Assemble the contact HR crossbar to the left and right handlebars using 18-bUTToN Head SCreW. Fasten the contact HR crossbar/handlebar assembly to the console masts using 15-bUTToN Head SCreW aNd 12-flaT WaSHer.
  • Page 65 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.3 aSSembly iNSTrUCTioNS - CoNTiNUed STeP 4 STeP 5 T1xe/T3xe SHoWN T1xe/T3xe SHoWN Re-assemble motor cover to treadmill base using Pre-aTTaCHed SCreWS. Open blaCk HardWare baG. Assemble the console to the handlebars using 14-SoCkeT Head CaP SCreW. Be sure to route the before THe firST USe: console cables down the console mast and connect the contact Lubricate the treadmill deck by following the instructions in the...

  • Page 66: Mye Tv Bracket Installation Instructions

    CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.4 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS 1) Remove the 2 screws holding the console back cover on and remove the back cover (Figures A & B). fiGUre a fiGUre b 2) Use a razor to remove the existing HR overlay on the console (Figure C). 3) Slide the ribbon cable of the entertainment keypad / overlay through the slot in the console (Figure D).
  • Page 67 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.4 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed fiGUre G fiGUre H fiGUre i fiGUre j fiGUre k fiGUre l...
  • Page 68 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.4 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 13) Connect the coax extension cable to the cable coming from the base of the unit (Figure M). 14) Mount the TV to the bracket using 4 screws sent with the TV (Figure N). fiGUre m fiGUre N 15) Make sure that the tabs on the front plate are tucked behind the console faceplate to create a seamless look (Figure O).
  • Page 69 20) Install the console back cover removed in Step 2 (Figure U). NOTE: Make sure that the coax, power, and controller wires are tucked in the slot in the cover (created by removing the small Matrix logo cover) (Figure V).
  • Page 70 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.4 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 23) Plug the TV power wire into the port at the base of the treadmill (Figure Y). 24) A channel scan should be done using the instructions included in the TV owner's manual. fiGUre y...

  • Page 71: Pctv Bracket Installation Instructions

    CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.5 PCTV braCkeT iNSTallaTioN iNSTrUCTioNS 1) Remove the 2 screws holding the console back cover on and remove the back cover (Figures A & B). fiGUre a fiGUre b 2) Cut the wire tie holding the coax cable, power wire, net wire, and controller wire to the console frame (Figure C). 3) Mount the TV bracket to the frame using 4 socket head screws sent with the bracket kit (Figure D).
  • Page 72 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.5 PCTV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 7) Mount the front plate to the TV using 2 screws sent with the bracket kit (Figure G). 8) Connect the power wire extension wire to the power wire coming from the base of the unit (Figure H). fiGUre G fiGUre H 9) Install the coax adaptor sent with the bracket kit to the coax cable coming from the base of the unit (Figure I), and connect the coax...
  • Page 73 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.5 PCTV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed NOTE: The wire connections in steps 12 - 15 should be done prior to installing the TV onto the bracket as the bracket will prevent some of the connections from being made. 12) Plug the coax cable into the port on the TV (Figure M).
  • Page 74 20) Install the console back cover removed in Step 2 (Figure U). NOTE: Make sure that the coax, power, net, and controller wires are tucked in the slot in the cover (created by removing the small Matrix logo cover) (Figure V).
  • Page 75 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.5 PCTV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 23) Plug the TV power wire into the port at the base of the treadmill (Figure Y). 24) Plug a network cable into the port at the base of the treadmill is using wired internet (Figure Z). fiGUre y fiGUre z 25) The PCTV should now be programmed as outlined in the PCTV owner's or service manuals.

  • Page 76: Software Upgrade Instructions

    1. Create an access on the USB flash drive which will be used. The access should be MATRIX\FW\UCB (create a folder called MATRIX, then a folder in MATRIX called FW, then a folder in FW called UCB). Or you can put the USB flash drive into the console and hold the PAUSE and Manual keys on the keypad for 3 second and the USB flash drive will automatically be formatted (Figure A).
  • Page 77 NoTeS...
  • Page 78 SS Sy S Te m S C or P. 1610 LAN DMARK  D RI VE  C OTTA G E  G R OV E  W I 5 352 7 U S A TOLL FREE 866.693.4 863 ww w.m atr i xfi t nes s . co m FA X 60 8.8 39 .1 717...
