Matrix T3xe Owner's Manual

Hide thumbs Also See for T3xe:
Table of Contents

Advertisement

Quick Links

See also: Console Manual , Manual
T3xe
T3x
T1xe
T1x
TREADMILL OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Matrix T3xe

Summary of Contents for Matrix T3xe

  • Page 1 T3xe T1xe TREADMILL OWNER’S MANUAL...

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS SAVE THESE INSTRUCTIONS When using an electrical product, basic precautions should always be followed, including the following: Read all instructions before using this treadmill. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions.
  • Page 4 dANGER TO REdUCE THE RISk Of ElECTRICAl SHOCk: Always unplug the treadmill from the electrical outlet immediately after using, before cleaning, performing maintenance and putting on or taking off parts. CAUTION If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness of breath, stop exercising immediately and consult your physician before continuing.
  • Page 5 WARNING (CONT.) • At NO time should pets or children under the age of 13 be closer to the treadmill than 10 feet. • At NO time should children under the age of 13 use the treadmill. • Children over the age of 13 or disabled persons should not use the treadmill without adult supervision. •...

  • Page 6: Electrical Requirements

    CIRCUIT ANd ElECTRICAl INfO All Matrix units require the use of a 15 amp or 20 amp “dedicated circuit, ” with a non-looped (isolated) neutral/ground, for the power requirement. Quite simply this means that each outlet you plug into should not have anything else running on that same circuit. The easiest way to verify this is to locate the main circuit breaker box, and turn off the breaker(s) one at a time.

  • Page 7: Grounding Instructions

    120V UNITS The Matrix T5x, T7x and T7xe 120 treadmill is for use on a nominal 120-volt circuit and has a non-looped grounding plug. Make sure that the 110-volt treadmill is connected to an outlet, NEMA 5-20R, having the same configuration as the plug. No adapter should be used with this product.

  • Page 9: Basic Operation

    BASIC OPERATION...

  • Page 10: Location Of The Treadmill

    lOCATION Of THE TREAdMIll 12” 300 mm Place the treadmill on a level and stable surface. Please leave a clear zone behind the treadmill that is at least the width of the treadmill and at least 79” (2000 mm) long. This zone must be clear of any obstruction and provide the user a clear exit path from the machine.

  • Page 11: Leveling The Treadmill

    lEVElING THE TREAdMIll Use of shim or adding leveling foot. NOTE: It is extremely important that the levelers are correctly adjusted for proper operation. An unbalanced unit may cause belt misalignment or other issues. Use of a level is recommended. Remove the leveling shim provided on the underside of the treadmill.

  • Page 12: Tensioning The Running Belt

    TENSIONING THE RUNNING bElT After placing the treadmill in the position it will be used, the belt must be checked for proper tension and centering. The belt might need to be adjusted after the first two hours of use. Temperature, humidity, and use cause the belt to stretch at different rates. If the belt starts to slip when a user is on it, be sure to follow the directions below.
  • Page 13 TIGHTENS RIGHT SIdE Of ROllER TIGHTENS lEfT SIdE Of ROllER bElT IS TOO fAR TO THE RIGHT SIdE bElT IS TOO fAR TO THE lEfT SIdE...

  • Page 14: Using The Heart Rate Function

    USING THE HEART RATE fUNCTION The heart rate function on this product is not a medical device. While heart rate grips can provide a relative estimation of your actual heart rate, they should not be relied on when accurate readings are necessary. Some people, including those in a cardiac rehab program, may benefit from using an alternate heart rate monitoring system like a chest or wrist strap.

  • Page 15: Wireless Heart Rate Receiver

    WIRElESS HEART RATE RECEIVER When used in conjunction with a wireless chest transmitter, your heart rate can be transmitted wirelessly to the unit and displayed on the console. Prior to wearing the wireless chest transmitter on your chest, moisten the two rubber electrodes with water. Center the chest strap just below the breast or pectoral muscles, directly over your sternum, with the logo facing out.

  • Page 17: Troubleshooting And Maintenance

    TROUBLESHOOTING & MAINTENANCE...

  • Page 18: Deck And Belt Replacement

    The Matrix Ultimate Deck™ Use a mild soap and damp cloth. DO NOT use ammonia does not require any maintenance, other than cleaning and belt based cleaner.

  • Page 19: Check For Damaged Parts

    Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so. Matrix Fitness Systems will provide service and maintenance training at our corporate facility upon request...

  • Page 21: Treadmill Assembly

    ENTER YOUR SERIAL NUMBER AND MODEL NAME IN THE BOXES BELOW: PLACEMENT SERIAl NUMbER lOCATION CONSOLE SERIAL NUMBER: FRAME SERIAL NUMBER: MATRIX MODEL NAME: » Refer to the SERIAL NUMBER and MODEL NAME when calling for service. *The console serial number can be found in the Manager Mode.
  • Page 24 REQUIRED fASTENERS Frame set Part name Outline Spec. Qty. Color Blue M8x1.25Px25L (Chromed) SOCKET HEAD CAP SCREW Blue Ø8.2xØ19x2.0t (Chromed) FLAT WASHER Black M8x1.25Px20L (BED) SOCKET HEAD CAP SCREW White M8x1.25Px20L (Chromed) BUTTON HEAD SCREW White Ø8.2xØ19x2.0t (Chromed) FLAT WASHER Console set Part name Outline...

  • Page 25: Required Tools

    REQUIRED TOOlS QUANTITY SKETCH DESCRIPTION PAKEAGE COLOR PURPLE 6mm ALLEN WRENCH PURPLE 5mm ALLEN WRENCH PURPLE PHILLIPS DRIVER(6x130mm) PURPLE 8mm ALLEN WRENCH...

  • Page 26: Assembly Step

    ASSEMBLY STEp 1 Cut the yellow banding straps and lift the running deck upward to remove all contents from underneath the running deck. Open hardware bag 1. Slide main frame boot up console mast. Place right console mast over main frame bracket.

  • Page 27: Open Hardware Bag

    ASSEMBLY STEp 2 Open hardware bag 2. blUE HARdWARE bAG CONTENTS : With the console upside down, attach the FLAT WASHER console mast caps to the console SOCKET HEAD CAP SCREW Qty: 8 Qty: 8 using 4 bolts (e) and 4 spring washers (b).
  • Page 28 ASSEMBLY STEp 3 Open HARdWARE bAG 3. WHITE HARdWARE bAG CONTENTS : Slide CONSOlE through the CONSOlE BUTTON HEAD SCREW FLAT WASHER SOCKET HEAD CAP SCREW Qty: 6 MAST bOOTS. Qty: 6 Qty: 6 NOTE: Make sure the arrows on the mast rings are pointing upward towards the console when sliding into place.
  • Page 29 ASSEMBLY STEp 4 Open HARdWARE bAG 4. Attach MAIN fRAME bOOTS using 4 SCREWS (d). N58 N57 Before the first use, lubricate the treadmill deck by following the instructions in the MAINTENANCE section in the TREADMILL GUIDE.
  • Page 30 ASSEMBLY STEp 5 Open HARdWARE bAG 3. yEllOW HARdWARE bAG CONTENTS : Slide CONSOlE through the CONSOlE SOCKET HEAD CAP SCREW MAST bOOTS. Qty: 4 NOTE: Make sure the arrows on the mast rings are pointing upward towards the console when sliding into place.
  • Page 31 ASSEMBLY STEp 6 Open HARdWARE bAG 4. Attach MAIN fRAME bOOTS using 4 SCREWS (d). Before the first use, lubricate the treadmill deck by following the instructions in the MAINTENANCE section in the TREADMILL GUIDE. ASSEMBLY COMPLETE!

  • Page 33: Treadmill Operation

    TREADMILL OPERATION...
  • Page 34 MANAGER pREfERENCE MOdE 1X,3X CONSOlES: This section allows a user to manipulate default settings for the machines. It may be accessed by pressing the level Up/level down keys simultaneously for 5 seconds. To change a setting, press “Enter” on the keypad and use the Level buttons and numeric keypad to change the values.
  • Page 35 CONSOlE dESCRIpTION: The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material.
  • Page 37 T1X CONSOlE dESCRIpTION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. A) WORkOUT kEyS: Simple program view and selection buttons. Press Fitness Test button to cycle through available tests. b) QUICk START/GO: One Touch Start and Quick Start.

  • Page 39: T3X Console Description

    T3X CONSOlE dESCRIpTION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. A) MUlTI-pURpOSE kEyS: Keys have different functions depending on each screen. b) QUICk START/GO: One Touch Start and Quick Start. C) ENTER: To confirm each program setting.
  • Page 41 T1XE CONSOlE dESCRIpTION The T1xe has a fully integrated touch screen display. All information required for workouts is explained on screen. Exploration of the interface is highly encouraged. The information explaining how to program for various workouts will give an explanation about the contents of each screen on the T7xe.
  • Page 43 T3XE CONSOlE dESCRIpTION The T3xe has a fully integrated touch screen display. All information required for workouts is explained on screen. Exploration of the interface is highly encouraged. The information explaining how to program for various workouts will give an explanation about the contents of each screen on the T3xe.

  • Page 44: Level Based Programs

    5) Press GO to begin the workout. kEyS and press ENTER. 5) Enter the desired start speed using the ARROW kEyS To enter into this workout on a T1xe or T3xe, follow the and press ENTER. onscreen prompts. 6) Press GO to begin the workout.
  • Page 45 4) Press GO to begin the workout. 5) Press GO to begin the workout. To enter into this workout on a T1xe or T3xe, follow the To enter into this workout on a T1xe or T3xe, follow the onscreen prompts.

  • Page 46: Fit Test

    The Matrix T1x & T1xe treadmills offer a Gerkin firefighter The heart rate control workout mode allows the user to program protocol fitness test. The T3x and T3xe offer a variety of fitness their desired heart rate zone and maximum allowable incline and...
  • Page 47 7) Press GO to begin the workout. 8:45 9:00 70.7 10.1 9:15 72.1 10.2 9:30 73.1 To enter into the Gerkin testing workout on a T1xe or a T3xe, 10.3 9:45 73.8 follow the onscreen prompts. 10.4 10:00 74.9 11.1 10:15 76.3...

  • Page 48: Cardiovascular Fitness Percentiles

    CARdIOVASCUlAR fITNESS pERCENTIlES The WFI (Wellness Fitness Initiative) protocol is a modified Gerkin test used by firefighters to evaluate aerobic fitness capacity as part of Males: VO2 max (ml/kg/min) pre-employment testing and annual fitness testing. The goal is to meet 20-29 30-39 40-49...
  • Page 49 5) Enter the desired start speed using the ARROW kEyS or the NUMbER kEypAd and press ENTER. 6) Press GO or QUICk START to begin the workout. To enter into a Military Fitness Test workout on a T3xe, follow the onscreen prompts.

  • Page 50: Usb Features

    USb fEATURES • Software Updates • USB Charging • Record Workout Statistics to USB • Upload Workout Statistics to www.livestrong.com SOfTWARE UpdATES Note: The USB drive does not need to be in the entire workout. It must be inserted before the workout summary screen ends or The USB port is used to update the console firmware.

  • Page 53: Product Specifications

    PRODUCT SPECIFICATIONS...
  • Page 54 0.5 - 12 MPH 0.5 - 12 MPH CONTACT & TELEMETRIC HR SENSORS DRIVE SYSTEM MOTOR MATRIX 4.2 HP AC DYNAMIC RESPONE DRIVE SYSTEM™ MATRIX 4.2 HP AC DYNAMIC RESPONE DRIVE SYSTEM™ MOTOR CONTROLLER COMMERCIAL TREADMILL AC DRIVE COMMERCIAL TREADMILL AC DRIVE...
  • Page 55 0.5 - 12 MPH 0.5 - 12 MPH CONTACT & TELEMETRIC HR SENSORS DRIVE SYSTEM MOTOR MATRIX 3.0 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MATRIX 3.0 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MOTOR CONTROLLER COMMERCIAL TREADMILL AC DRIVE COMMERCIAL TREADMILL AC DRIVE...
  • Page 56 Matrix fitness 1-866-693-4863 1600 landmark drive, www.matrixfitness.com Cottage Grove, WI 53527 Matrix Treadmills Rev 1.5 | © 2012 Matrix Fitness...

This manual is also suitable for:

T3xT1xeT1x
