Temperature sensor
2
•
I C temperature sensor.

Battery backup

•
On-board battery holder containing a lithium-ion non-rechargeable CR2032, 3V,
TL
220mAh battery.
•
Battery disconnect jumper.
TL
Test support
•
JTAG interface (10-pin header).
•
Download data to FLASH memory.
•
Debug and connection to In-Circuit Emulator (ICE).

Power requirements

•
Typically 1.5W from a single 5V supply.
•
Power management features allow current requirements to be as low as 20mA
(100mW) in sleep mode and 2mA (10mW) in deep sleep mode.
Mechanical
•
PC/104 compatible footprint 3.8" x 3.6" (96mm x 91mm)
Environmental
•
Operating temperature:
- Commercial: 20°C (-4°F) to +70°C (+158°F) for speed variants up to 520MHz.
- Industrial: -40°C (-40°F) to +85°C (+185°F) for speed variants up to 416MHz.
•
RoHS Directive Compliant (2002/95/EC).
