TITAN user manual
Date/time support
•
Real time clock – battery backed on-board (external to PXA270).
•
± 1 minute/month accuracy.
Video
•
18-bit flat panel interface for STN and TFT displays on 40-pin boxed connector.
•
Up to 800x600 resolution.
•
8/16bpp.
•
Backlight control.
•
Optional LVDS interface.
TL
•
LCD voltage (3.3V / 5V) selection jumper.
•
LVDS encoding mode selector jumper (for signalling decoding LVDS display
TL
receiver).

Audio and touchscreen

•
Wolfson WM9712L AC'97 compatible CODEC.
TL
•
Line in, line out, microphone in, stereo amp out on 12-pin boxed header.
TL
•
Touchscreen support: 4/5-wire analogue resistive on 5-pin boxed header.
TL
Quick Capture camera interface
®
•
Intel Quick Capture technology.
•
20-pin boxed header connector to a camera image sensor.
2
I C bus
•
Multi-master serial bus, header connection.
Configuration PROM
2
•
I C PROM for storing configuration data.
Watchdog timer
•
External to PXA270, generates reset on timeout. Timeout range 1ms-60s.
User configuration
•
Three user configurable jumpers on 8-pin header.
General I/O
•
Sixteen user configurable general purpose I/O on 20-pin boxed header.
•
5V tolerant inputs.
•
3.3V outputs, pulled up to 5V.
•
PWM outputs for LED intensity control
8
Issue D
