TITAN user manual
Using the USB host
The standard USB connector is a 4-way socket, which provides power and data signals
TL
to the USB peripheral. The 10-way header J10 has been designed to be compatible with
PC expansion brackets that support two USB sockets. See the sections USB, page 43,
and J10 – USB
Using the USB client
The TITAN USB host port 2 can be configured under software to be a client and
connected to a PC via a USB cable This feature is standard for the TITAN-Lite. The USB
cable should be plugged into the 10-way header J10. See the sections USB, page 43,
and J10 – USB
Using the Ethernet interface
The Davicom DM9000A 10/100BaseTX Ethernet controller is configured by the RedBoot
boot loader for embedded Linux, and by Windows CE once it has booted. Connection is
made via connector J11. A second connector J12 provides link and speed status outputs
for control LEDs. See the sections Ethernet, page 45;
connector,
details.
Using the PC/104 expansion bus
PC/104 modules can be used with the TITAN to add extra functionality to the system.
TL
This interface supports 8/16-bit ISA bus style peripherals.
Eurotech has a wide range of PC/104 modules that are compatible with the TITAN.
These include modules for digital I/O, analogue I/O, motion control, video capture, CAN
bus, serial interfaces, etc. Please contact the Eurotech sales team if a particular interface
you require does not appear to be available as these modules are in continuous
development. Contact details are provided in
101.
To use a PC/104 board with the TITAN, plug it into J13 for 8-bit cards and J13/J14 for
8/16-bit cards. See the sections
connectors,
The ISA interface on the TITAN does not support DMA, shared interrupts and some
access modes. See the section
interrupt use.
The TITAN provides +5V to a PC/104 add-on board via the J13 and J14 connectors. If a
PC/104 add-on board requires a +12V supply, then +12V must be supplied to the TITAN
power connector J15 pin 4. If –12V or –5V are required, these must be supplied directly
to the PC/104 add-on board.
The TITAN is available with non-stack through connectors by special order. Contact
Eurotech for more details (see
14
connector, page 72, for further details.
connector, page 72, for further details.
page 72; and J12 – Ethernet status LEDs
PC/104
page 74, for further details.
PC/104
Eurotech Group Worldwide
J11 – 10/100BaseTX Ethernet
connector, page 73, for further
Eurotech Group Worldwide
interface, page 29, and J14 & J15 – PC/104
interrupts, page 30, for details about PC/104
Presence, page 101).
Presence, page
Issue D
