TITAN user manual

TITAN address map

PXA270 chip select Physical address
CS0#
CS1#
-
CS4#
TL
-
CS4#
-
CS4#
-
CS4#
-
CS4#
-
CS4#
-
CS4#
-
CS5#
TL
-
NA
TL
-
NA
TL
-
NA
NA
NA
NA
TL
NA
-
NA
NA
NA
NA
NA
-
SDCS0#
-
1
Details of the internal registers are in the Intel Developer's Manual on the Development Kit CD.
16
0x00000000 – 0x03FFFFFE
0x04000000 – 0x07FFFFFE
0x08000000 – 0x0FFFFFFF
0x10000000 – 0x1000000E
0x10000010 – 0x107FFFFF
0x10800000 – 0x1080000E
0x10800010 – 0x10FFFFFF
0x11000000 – 0x11000001
0x11000002 – 0x117FFFFF
0x11800000 – 0x11800001
0x11800002 – 0x11FFFFFF
0x12000000 – 0x12000001
0x12000002 – 0x127FFFFF
0x12800000 – 0x12800001
0x12800002 – 0x12FFFFFF
0x13000000 – 0x13000001
0x13000002 – 0x13FFFFFF
0x14000000 – 0x17FFFFFE
0x18000000 – 0x1FFFFFFF
0x30000000 – 0x300003FF
0x30000400 – 0x3BFFFFFF
0x3C000000 – 0x3C1FFFFF
0x3C200000 – 0x3FFFFFFF
0x40000000 – 0x43FFFFFF
0x44000000 – 0x47FFFFFC
0x48000000 – 0x4BFFFFFC
0x4C000000 – 0x4FFFFFFC 32-bit
0x50000000 – 0x53FFFFFC
0x54000000 – 0x57FFFFFC
0x58000000 – 0x5BFFFFFC
0x5C000000 – 0x5C00FFFC 32-bit
0x5C010000 – 0x5C01FFFC 32-bit
0x5C020000 – 0x5C02FFFC 32-bit
0x5C030000 – 0x5C03FFFC 32-bit
0x5C040000 – 0X7FFFFFFF -
0x80000000 – 0x8FFFFFFF
0x90000000 – 0xFFFFFFFF
Bus width Description
16-bit FLASH memory / Silicon disk
16-bit Ethernet controller
- Reserved
16-bit COM4
- Reserved
16-bit COM5
- Reserved
16-bit BV_REG (Board version / issue)
- Reserved
16-bit I2_REG (PC104 IRQ status)
- Reserved
16-bit CV_REG (CPLD version / issue)
- Reserved
16-bit I1_REG (PC104 IRQ status)
- Reserved
16-bit C_REG (PC104 reset)
- Reserved
16-bit SRAM
- Reserved
8/16-bit PC/104 I/O space
- Reserved
8/16-bit PC/104 memory space
- Reserved
32-bit PXA270 peripherals
32-bit LCD control registers
32-bit Memory controller registers
USB host registers
32-bit Capture Interface registers
- Reserved
32-bit Internal memory control
Internal SRAM bank 0
Internal SRAM bank 1
Internal SRAM bank 2
Internal SRAM bank 3
Reserved
32-bit SDRAM
- Reserved
1
1
1
1
1
1
Issue D
