TITAN user manual
JP2 – LCD logic supply selection
Connector: Oupiin 2011-1x3GSB/SN, 3-way, 2.54mm (0.1") single row through-hole
header.
Pin Signal name
1 VCC_PER (+5V)
2 LCD logic supply
3 +3V3
JP3 – LVDS MSL selection
Connector: Oupiin 2011-1x2GSB/SN, 2-way, 2.54mm (0.1") single row through-hole
TL
header.
Pin Signal name
1 MSL
2 +3V3
JP4 – User / Recovery link selection
Connector: Oupiin 2015-2x4GDB/SN, 8-way, 2.54mm (0.1") dual row surface mount
header.
Pin Signal name
1 GND
3 GND
5 GND
7 GND
JP5 – External reset
Connector: Oupiin 2011-1x2GSB/SN, 2-way, 2.54mm (0.1") single row through-hole
header.
Pin Signal name
1 /Reset
2 +GND
76
Pin Signal name
2 USER_LINKA
4 USER_LINKB
6 USER_LINKC
8 RECOVERY
3 1
1
2
7 1
8 2
2 1
