Eurotech Titan User Manual

Pc/104 single board computer
Hide thumbs Also See for Titan:

Advertisement

Quick Links

Download this manual See also: User Manual
USER MANUAL
TITAN Development Kit
PC/104 Single Board Computer
Issue A – October 2011 – ETH_TITAN_DEVKIT_USM
DIGITAL TECHNOLOGIES FOR A BETTER WORLD
www.eurotech.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Titan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eurotech Titan

Summary of Contents for Eurotech Titan

  • Page 1 USER MANUAL TITAN Development Kit PC/104 Single Board Computer Issue A – October 2011 – ETH_TITAN_DEVKIT_USM DIGITAL TECHNOLOGIES FOR A BETTER WORLD www.eurotech.com...

  • Page 2: Warranty

    TITAN - user manual WARRANTY For Warranty terms and conditions users should contact their local Eurotech Sales Office. TRADEMARKS All trademarks both marked and not marked appearing in this document are the property of their respective owners. REVISION HISTORY Issue no.
  • Page 3 Connectors Connectors TITAN-Breakout board The following diagrams show the location of the connectors and jumpers on the TITAN-Breakout. Top view J15 (I2C) S1 (Power On) S2 (reset) Front view J3 (Ethenet /USB) J1 (power) J2(USB client) J4 (VGA) J5 (Audio)
  • Page 4 TITAN - user manual Connectors Connector Function Power Jack USB Client Ethernet and dual USB Audio GPIO COM1 RS232 COM2 RS232 COM3 RS232 COM4 RS232 COM5 RS422/485 Audio out right selection Audio out left selection ETH_TITAN_USM...
  • Page 5 Connectors J1 – +5V DC IN, 2.1mm jack Signal name Positive terminal (+12V) Sleeve Negative terminal (0V) J2 – USB Client Signal name USB_VCC USB_D- USB_D+ J3 – Ethernet and USB1/2 Ethernet Signal name LINK USB1/2 Signal name Signal name (top) (bottom) USB_VCC2...
  • Page 6 TITAN - user manual J4 –VGA connector Signal name Signal name GREEN BLUE DDC_SDA HSYNC VSYNC DDC_SCL ETH_TITAN_USM...

  • Page 7: Line In, Mic, Line Out - Audio Connectors

    Connectors J5 – Audio jacks Signal name LINE_IN_L Ring LINE_IN_R Sleeve Signal name LINE_OUT_L Ring LINE_OUT_R Sleeve Signal name MIC_IN Ring Sleeve Ground LINE IN, MIC, LINE OUT – Audio connectors 3.5mm stereo audio jacks are used for audio connection. The audio connectors are illustrated in the following diagram: Ring Sleeve...
  • Page 8 TITAN - user manual J6 – GPIO connector Signal name Signal name J15 – I2C Signal name +3V3 I2C_SDA I2C_SCL J16 – COM1 (RS232 serial port) Signal name Signal name ETH_TITAN_USM...
  • Page 9 Connectors J17 – COM2 (RS232 serial port) Signal name Signal name J18 – COM3 (RS232 serial port) Signal name Signal name J19 – COM4 (RS232 serial port) Signal name Signal name...
  • Page 10 TITAN - user manual J20 – COM5 (RS422/485 serial port) Signal name Signal name RX/TX+ RX/TX- JP1 – Headphones out right selection Signal name LINE_OUT_R HP_OUT_R SPK_OUT_R JP2 – Headphones out left selection Signal name LINE_OUT_L HP_OUT_L SPK_OUT_L ETH_TITAN_USM...
  • Page 11 Web: www.parvus.com Web: www.eurotech.com France EUROTECH Tel. +33 04.72.89.00.90 +33 04.78.70.08.24 E-mail: sales.fr@eurotech.com E-mail: support.fr@eurotech.com Web: www.eurotech.com Finland EUROTECH www.eurotech.com Tel. +358 9.477.888.0 +358 9.477.888.99 E-mail: sales.fi@eurotech.com E-mail: support.fi@eurotech.com Web: www.eurotech.com To find your nearest contact refer to: www.eurotech.com/contacts...
  • Page 12 TITAN - user manual www.eurotech.com EUROTECH HEADQUARTERS Via Fratelli Solari 3/a 33020 Amaro (Udine) – ITALY Phone: +39 0433.485.411 Fax: +39 0433.485.499 For full contact details go to: www.eurotech.com/contacts ETH_TITAN_USM...
