Eurotech Titan User Manual page 71

J8 – LVDS connector
Connector: Hirose
TL
pin header
LVDS mating connector: Hirose DF13-20DS-1.25C
LVDS mating connector crimps: Hirose DF13-2630SCFA
Eurotech recommended
Pin Signal name
1 +3V3
3 GND
5 LVDS_D0-
7 GND
9 LVDS_D1+
11 LVDS_D2-
13 GND
15 LVDS_CLK+
17 NC
19 GND
J9 – JTAG connector
Connector: Oupiin 2015-2X5GDB/SN, 10-way, 2.54mm (0.1") x 2.54mm (0.1") dual row
header
Mating connector: FCI 71600-010LF
Pin Signal name
1 +3V3
3 GND
5 NC
7 TDO
9 TCLK
Issue D
DF13-20DP-1.25V(55), 20-way, 1.27mm (0.05") double row straight
cable: Amphenol 165-2899-945
Pin Signal name
2 +3V3
4 GND
6 LVDS_D0+
8 LVDS_D1-
10 GND
12 LVDS_D2+
14 LVDS_CLK-
16 GND
18 NC
20 MSL
Pin Signal name
2 NC
4 nTRST
6 TDI
8 TMS
10 SRST
Connectors, LEDs and jumpers
20
19
2
1
71
