JP6 – JTAG enable
Connector: Oupiin 2011-1x2GSB/SN, 2-way, 2.54mm (0.1") single row through-hole
header
Pin
Signal name
1
VCC (+5V)
2
VCC_JTAG
This jumper is used to enable debug of PXA270 using JTAG interface.
JP6
Only insert jumper for JTAG access to PXA270. The
jumper MUST be removed when the JTAG interface is
not in use.
Issue D
Description
JTAG Enable
Normal Operation (Default)
Connectors, LEDs and jumpers
1
2
77
