Speaker installation example Speaker installation example
Installation on a floor or shelf
Ceiling installation
Wall mounting
TD508MK3 only
･ Make fine adjustments to the speaker angle. ➡Refer to P.32.
･ Adjust the angle of the speaker arm. ➡Refer to P.34.
･ Installation summary ➡Refer to P.37.
･ Determine the speaker installation angle. ➡Refer to P.38 - 39.
･ Install the speaker on the ceiling. ➡Refer to P.41 - 47.
･ Make fine adjustments to the speaker angle. ➡Refer to P.32.
Tip
The CB1 mounting bracket available separately should
be used to provide the most flexible installation.
･ Installation summary ➡Refer to P.37.
･ Determine the speaker installation angle. ➡Refer to P.40.
･ Install the speaker on the wall. ➡Refer to P.41 - 47.
･ Make fine adjustments to the speaker angle. ➡Refer to P.32.
Caution
The only speaker which can be installed on a wall is the
TD508MK3. The TD510MK2 cannot be installed on a
wall.
Tip
The CB1 mounting bracket available separately should
be used to provide the most flexible installation.
