MANUAL No. 090003-32270700

OWNER'S MANUAL

･Thank you for purchasing this product.

･Please read this owner's manual thoroughly prior to carrying out installation and connections.

･ Depending on the specific installation specialised skills maybe required. In such a case, please consult a

qualified technician.

･Installation by two people is always advised.

Keep this Owner's Manual together with the Warranty Certificate in a safe place for later reference.

Table of Contents

Need help?

Do you have a question about the TD508MK3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eclipse TD508MK3

Page 1 MANUAL No. 090003-32270700 OWNER'S MANUAL ･Thank you for purchasing this product. ･Please read this owner's manual thoroughly prior to carrying out installation and connections. ･ Depending on the specific installation specialised skills maybe required. In such a case, please consult a qualified technician.
Page 2: Table Of Contents
Contents Contents Parts list Before Safety guidelines installation Checklist before use Speaker installation example Parts and connections Adjusting the speaker angle Installing the speaker grille Installation On a floor or shelf On a ceiling or wall Care / Specifications Warranty and After Service Bracket installation positioning template Parts list Parts list...
Page 3: Checklist Before Use
Safety guidelines Safety guidelines The following WARNING and CAUTION signs are used throughout this owner’s manual as well as on the product. These signs alert the installer and users of important safety information to avoid risk of injury and damages to the product.
Page 4 ･ Make fine adjustments to the speaker angle. ➡Refer to P.32. Caution The only speaker which can be installed on a wall is the TD508MK3. The TD510MK2 cannot be installed on a wall. The CB1 mounting bracket available separately should be used to provide the most flexible installation.
Page 5: Parts And Connections
Parts and connections Parts and connections ※ The diagrams are for the TD508MK3 are the same for the TD510MK2. ❶ Speaker Side with mark 3 main positions ：Default Hexagonal head screw Side with mark Speaker angle adjustment nut Speaker arm...
Page 6: Adjusting The Speaker Angle
Adjusting the speaker angle Adjusting the speaker angle Spread a soft cloth over the floor in order to prevent damaging the surface of the speaker. Place the speaker on its side. Loosen the speaker angle adjustment nut on the under side of the speaker arm.
Page 7: Installing The Speaker Grille
Installing the speaker grille Installing the speaker grille ❶ Speaker Install the grille as shown in the illustration. ･ The grille may be attached when the speaker is not in use or at the users discretion. ･ Clip the edge of the grille to secure it. ❷...
Page 8 On a floor or shelf On a floor or shelf - Adjusting the angle of the speaker arm - ･ If you wish to use the speaker at the standard angle position (as it is when removed from its packaging), there is no need to adjust the angle.
Page 9 ❸ Hexagonal wrench Spread a soft cloth over the floor in order to prevent (large) damaging the surface of the speaker. Place the speaker on its side. Retaining bolt Remove the retaining bolt and the angle adjustment bolt ❹ from the speaker arm side with the mark.
Page 10 ❶ Speaker Stand the speaker upright. Replace the safety cable, fixing to the base as shown. Install the cover over the speaker base. Speaker base cover Speaker base Screw Safety cable ❶ Speaker Spread a soft cloth over the floor in order to prevent damaging the surface of the speaker.
Page 11: On A Ceiling Or Wall
On a ceiling or wall On a ceiling or wall ( The bracket (CB1) which is sold separately is required.) This product can be installed on ceilings and walls. If installing on a ceiling or a wall, you will need to use extra screws (sold separately).
Page 12 - Installing on a ceiling (installation example) - ■ Standard speaker arm type Select an installation method for the speaker arm in accordance with the speaker installation angle that will be used at the installation location. ･ The installation angle can be varied within a wide range by means of the direction of the speaker arm and the fixing holes used.
Page 13 ■ Reverse speaker arm type Speaker base Caution Be careful not to get your hand or fingers caught in the movable part of the speaker arm. Speaker arm The position of the fixing hole (mark) is important when assembling the speaker and the speaker arm. For details, refer to “Assembling the speaker”...
Page 14 The only speaker which can be installed on a wall is the Speaker arm TD508MK3. The TD510MK2 cannot be installed on a wall. Select an installation method for the speaker arm in accordance with the speaker installation angle that will be used at the installation location.
Page 15 - Preparation for installation - Remove the hexagonal head bolt from the speaker arm. Rear view of the speaker The hexagonal head bolt which is removed will be used later, so be careful not to lose it. Hexagonal head bolt Hexagonal head bolt Speaker angle adjustment nut Speaker arm...
Page 16 ❶ Speaker Stand the speaker upright. Remove the base cover. Remove the safety cable from the speaker base. Speaker base cover Remember to retain the screw as it will be used later. Speaker base Screwdriver Screw Safety cable Lift up the speaker to remove it from the speaker arm. Caution ･...
Page 17 Safety cable the wire fixing point. CB1) (included with the CB1) ･ TD508MK3 speakers only: Use the screw (binding M5 x 8) that is included with the bracket. ･ TD510MK2 speakers only: Use the screw (binding Front M4 x 8) that is included with the bracket.
Page 18 - Installing the bracket - The illustration shows the speaker being installed on a ceiling, but carry out the same procedure if installing the speaker to a wall. Template Use the template in the back of this manual to determine the speaker installation position on the ceiling, and attach the template to the ceiling with tape.
Page 19 When securing the speaker to the bracket, turn the speaker base in the direction of the arrow marked on the speaker base to secure it. The illustration shows the TD508MK3. Speaker base Securely install the speaker base to the bracket.
Page 20 - Assembling the speaker - ❶ Grooves X3 Speaker Insert the locking pin of the speaker into the hole in Locking pin the speaker arm, and then secure it by tightening the speaker angle adjustment nut. Pins X3 Insert the locking pin into the hole in the speaker Speaker angle arm, and align the three pins with the grooves in the adjustment nut...
Page 21 Fix the safety cable securely to the surface so unit Safety cable cannot fall. (included with the CB1) Caution If the product is not securely fixed, there is a risk it could fall causing injury and or damage. Find a secure fixing point eg: a beam. Screw (sold separately) ❶...
Page 22: Care / Specifications
You can contribute to eliminate these effects and to enhance reuse/recycle/ other forms of recovery by your cooperation. ■ Specifications Specifications and appearance are subject to change without prior notification. 　●TD508MK3 　Driver diameter　：φ8cm 　Degaussing　　　：Degaussing design (JEITA) 　Allowable input　：Rated 15 W / Maximum 30 W 　Impedance　　　：8Ω...
Page 23 ■ Repairs and Enquiries Please contact the following or the store you purchased the goods. Eclipse TD (UK) Ltd. Tel : ＋44 (0) 20 7328 4499 Fax : ＋44 (0) 20 7624 6384 E-mail : info@eclipse-td.co.uk...
Page 24 − 50 −...
Page 25: Bracket Installation Positioning Template
(φ7 mm dia.) on the ceiling. Cut along the diagonal line. ■ For the TD508MK3 （ Speaker cable routing hole） The illustration at left shows the hole position when routing a speaker cable with a diameter of φ7 mm or less inside the speaker arm.
