OWNER'S MANUAL
･Thank you for purchasing this product.
･Please read this owner's manual thoroughly prior to making any connections.
･ If installation methods or non-standard parts not specified in this installation manual are used, accidents or
injury may result.
･ Specialised knowledge and experience is required in order to install the speaker to a ceiling or wall. In such
a case, please consult a qualified technician.
･Installation by two people is always advised.
Keep this Owner's Manual together with the Warranty Certificate in a safe place for future reference.
MANUAL No. 090003-35250700
Advertisement
Related Manuals for Eclipse TD508MK4
Summary of Contents for Eclipse TD508MK4
- Page 1 MANUAL No. 090003-35250700 OWNER'S MANUAL ･Thank you for purchasing this product. ･Please read this owner's manual thoroughly prior to making any connections. ･ If installation methods or non-standard parts not specified in this installation manual are used, accidents or injury may result. ･...
-
Page 2: Table Of Contents
Contents Contents Parts list Before Safety guidelines installation Checklist before use Speaker installation example Parts and connections Adjusting the speaker angle Installing the speaker grille Installation Reversing the position of the speaker arm to the base On a ceiling or wall Care / Specifications Warranty and customer service Parts list... -
Page 3: Safety Guidelines
Safety guidelines Safety guidelines The following WARNING and CAUTION signs are used throughout this owner’s manual as well as on the product. These signs alert the installer and users of important safety information to avoid risk of injury and damages to the product. -
Page 4: Speaker Installation Example
Speaker installation example Speaker installation example ･ Adjust the speaker angle. ➡Refer to P.22. Installation on a floor or shelf ･ Example of installation on a ceiling or wall. ➡ Refer to P.25. Ceiling installation ･ Install the speaker to the ceiling or wall. ➡Refer to P.26 - 30. ･... -
Page 5: Parts And Connections
Parts and connections Parts and connections ① Speaker Cable entry point (small) Cable entry point (large) (Black) (Red) Speaker wire Speaker arm Speaker input terminals Speaker base Speaker wire Cable entry point Speaker base Caution • When connecting the speaker wires, insert the bare ends of the speaker wires correctly so that they do not touch neighboring terminals, otherwise it may cause short-circuits. -
Page 6: Adjusting The Speaker Angle
Adjusting the speaker angle Adjusting the speaker angle Use the Allen key (large) which is supplied with the speaker to loosen the hex socket nut underneath the speaker. +35° -20° The speaker is heavy, so hold it with your hand when adjusting the angle. -
Page 7: Installing The Speaker Grille
Installing the speaker grille Installing the speaker grille Install the grille as shown in the illustration. ①Speaker • The grille may be attached when the speaker is not in use or at the users discretion. • Clip the edge of the grille to secure it. ②Grille - 23 -... -
Page 8: Reversing The Position Of The Speaker Arm To The Base
Reversing the position of the speaker arm to the base Reversing the position of the speaker arm to the base The TD508MK4 speaker can be installed in a variety of configurations by changing the way the speaker base and speaker arm are installed. ... -
Page 9: On A Ceiling Or Wall
On a ceiling or wall On a ceiling or wall This product can be installed on ceilings and walls. If installing on a ceiling or a wall, you will need to use extra screws (sold separately). When installing the speaker, be sure to fit the safety cable. Caution •... -
Page 10: Preparation For Installation
- Preparation for installation - Remove the screws from the bottom of speaker Screwdriver base. Screws x4 Speaker base ① Speaker Remove the speaker base cover. ① Speaker Speaker base cover Speaker base - 26 -... - Page 11 Remove the hex socket nut which are securing the ④ Allen key (large) speaker unit and the speaker arm. Mounting Mounting Hex socket nut Slide the speaker unit mounting bolt. hole bolt Remove the speaker arm from the speaker unit. Caution Speaker arm The speaker unit is heavy, so use care when...
- Page 12 Speaker base Fix the speaker base to the surface as shown using suitable screws (sold separately). Caution • Securely fix the speaker base to prevent the speaker from falling down. • When securing the speaker base to the ceiling or wall with the screws, tightening the screws too Screws (sold separately) much may distort the speaker base and prevent the base cover from being attached.
- Page 13 Route the speaker wires. Speaker wire ( 15 mm diameter • To make it easier to connect the speaker wires to or more) the speaker, leave about 11.8 inches (30 cm) of wire available. Speaker base ■ For speaker wire diameter less than φ15 mm Approx.
-
Page 14: Assembling The Speaker
- Assembling the speaker - Hex socket nut Insert the speaker mounting bolt into the mounting hole of the speaker arm, and then slide the mounting bolt. Tighten the hex socket nut by hand. Mounting Mounting bolt hole Fully tighten the hex socket nut with an Allen key (large). -
Page 15: Care / Specifications
Care / Specifications Care / Specifications ■Maintenance Before cleaning, be sure to turn off the power supply for all connected equipment and disconnect the power cords from the electrical outlets. Remove any dirt from the unit by lightly wiping with a soft dry cloth. If required moisten the cloth to remove surface dirt, then dry with a soft cloth. -
Page 16: Warranty And Customer Service
Warranty and customer service ■Customer service for enquiries related to usage, care, and repair of the product Your first point of contact should always be the ECLIPSE approved retailer who sold you the product, or the distributor of your country as they may be able to resolve the issue.
