Technical Specifications

2. Technical Specifications
Electrical Characteristics
External Power Supply
Operating Voltage Range
Input Current
Internal Backup Battery
Auxiliary Power Output
Display
PGM Open Collector Outputs
External Siren Output
Local Siren
Communication (RF) Characteristics
Frequencies
RF Jamming Detection
Anti-collision
Programmable No-activity Timer
Reporting
Two-Way Voice Communication
Telephone and Modem
Environmental Characteristics
Operating Temp. Range
Storage Temp. Range
Operating Humidity
Dimensions
Height x Width x
Depth
Weight
10
220 VAC/50 Hz, 110 VAC/60 Hz
15 VDC, 800 mA
Standby: 120 mA
Max: 500 mA (750 mA w/GSM expansion)
800 mAh for 6 hours standby
13.8 VDC, 500 mA max
Two Line, 16 characters, white backlit LCD
Two fully programmable, 200 mA, PTC protected
1 A relay
80 dBA
32ºF – 140ºF (0ºC – 60ºC) without battery
32ºF – 113ºF (0ºC – 45ºC) with battery
-13ºF – 158ºF (-25ºC – 70ºC)
0– 85% at 30ºC non-condensing
HLX-40
217 x 144 x 48 mm
(8.54 x 5.67 x 1.89
in.)
520g (1.15 lb)
433.92 MHz (G version)
868.35 MHz (H version)
UL/EN selectable
Proprietary RF protocol
1–30 hours, per zone
Three private telephone numbers.
Three private telephone numbers
Built in dialer & 2400 Baud modem
HLX-40A
217 x 144 x 50 mm
(8.54 x 5.67 x 1.97
in.
530g (1.17 lb)
HomeLogiX™ HLX-40 User Guide
HLX-40B
217 x 144 x 48 mm
(8.54 x 5.67 x 1.89
in.)
548g (1.21 lb)
