FUNCTION should be set to SELECT INPUT. Select the desired input (1 through 4). Set the
start date, end date, days of the week and the Start Time for the triggered event.
When you have all desired settings loaded, click OK to set the event in the scheduler.
ADD EXTRON SWITCHER EVENT
The MX system is capable of controlling external switcher devices via RS-232 serial control.
To add an EXTRON SWITCHER EVENT to your schedule, click
Communications and then MX Scheduler.
Click the EVENT tab and the ADD EVENT drop-down.
Select EXTRON CMS
