Standard Connection Definitions ('*' = required connection for normal operation; '+' = required
for initial setup only and may be removed after setup; all other connections not marked with '*'
or '+' are optional)
+ MOUSE: Standard PS/2 style mouse
+ KEYBOARD: Standard PS/2 style keyboard
USB 1 & 2: Universal Serial Bus (any number of add-in peripherals such as printer, mouse,
keyboard)
PARALLEL PORT: Standard printer port
IOIO: Standard RS-232 serial port
AUDIO LINE OUT: Connect with 3/8" Stereo plug to audio amplifier or switcher for audio
broadcast over cable or broadcast television system. Required if you desire audio on-air
capability.
AUDIO LINE IN: Use 3/8" stereo plug to connect radio receiver, CD player, tape player, etc...
to line-in to loop through external audio source over the video presentation.
AUDIO MIC IN: Can serve as microphone input or secondary audio source input.
*+ VIDEO Out: Depending on your model hardware one or multiple video connections can be
made simultaneously—Composite Video Out (BNC connector outputting standard baseband (un-
modulated) video) NTSC or PAL; DVI Out (typical for PC, HD or Flat Panel displays); RGBHV
Out (typical for PC, HD or Flat Panel displays).
NETWORK: RJ45 WAN/LAN port used to connect your MX to a network for remote control of
the device. Factory default setting for an MX player is Dynamic Host Configuration Protocol
(DHCP) used to force the player to automatically acquire an IP address.
CAUTION
If you must set or change the IP address in your MX and are unfamiliar with networks or do
not understand the steps in this manual, contact IT trained personnel prior to changing any
settings
*Main Power: Standard 100 to 220 VAC, 50 to 60 Hz input. Utilize the A/C power supply cord
and DC Transformer (if applicable) shipped with your unit. Connect this only when you are
ready to run the unit. As soon as you plug in the AC Main Power, the device will power-up,
Power-On-Self-Test (POST), and begin to run the current schedule.
