Mediazone Scheduler Software Installation; Minimum Editor System Recommendations; Install Software - KeyWest Technology MXB-AV Manual

MediaXtreme MediaZone

MediaZone Scheduler Software Installation

Minimum Editor System Recommendations

To enjoy the full features and functions of the scheduler software, including rendered full motion
previews, the following minimum requirements should be met:
--P4 at 2GHz (or better—Centrino© adequate for Laptops)
--400MHz Front Side Buss Motherboard
--256MB 2100 DDR RAM
--7200 RPM IDE HDD with at least 150MB open space
--CD-ROM or DVD-ROM drive
--High-Speed Internet Connection
--Video Card or Chipset equivalent to or better than ATI 9000 Rage© with 64MB Video
Memory
--Windows 2000 Pro© or Windows XP© Operating System
*****VISTA NOTE*****
For users with Windows Vista, when installing, right click on the SETUP.EXE package and
select RUN AS ADMINISTRATOR. Also, when running the software for the first time after
installation, right click on the start icon and again select RUN AS ADMINISTRATOR.
Failure to follow these steps will render some functions unusable on a VISTA loaded PC. In
addition, if the user does not have full administrator rights, regardless of operating system
installed, certain functions may not work or the entire application may fail to operate. Contact
the IT department or Keywest Technology with questions.
MediaXtreme systems are not compatible with Macintosh© Operating Systems but are run on
Mac computers using Windows emulator programs.
The scheduler software will run on older or less powerful machines, but fully rendered preview
will not be available. We will cover both preview versions later in this manual.

Install Software

Insert the CD that came with the system. If auto run is on a splash screen will appear—if the CD
doesn't auto-run, browse to the CD drive, and click autorun.exe.
Click the INSTALL MX SCHEDULER button. The Install Wizard should start.
Click NEXT then follow the on-screen prompts and instructions to install the software.
Install all the components listed. Failure to install one of those components might render a
feature or function unavailable.
