Select the event—LOGO ON or LOGO OFF—by selecting the appropriate radio button.
Set the event time, date, and days of week—when you are satisfied with the event click OK to
add it to the EVENT programming.
ADD SWITCHER EVENT
The MX system is capable of controlling external switcher devices via RS-232 serial control.
To add a SWITCHER EVENT to your schedule, click Communications
and then MX Scheduler.
Click the EVENT tab and the ADD EVENT drop-down.
Select SWITCHER EVENT
